Sick KTM-WN1A182V Contrast Sensor
The Sick KTM-WN1A182V Contrast Sensor offers Small, stainless steel, design β€ 11 mm sensing distance, 12 V DC ... 24 V DC supply voltage, NPN Output Cable with M12 male connector, 4-pin, 0.2 m; Cable with M12 male connector, 4-pin, 0.2 m connection. Manufactured by Sick under the Sick Contrast Sensor category, this model belongs to the KT Series.
| Brand | Sick |
| Product Type | Contrast Sensor |
| Model Number | KTM-WN1A182V |
Sick KTM-WN1A182V Contrast Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (W x H x D) | 15.25 mm x 48.6 mm x 22.2 mm |
| Sensing distance | β€ 11 mm |
| Sensing distance tolerance | Β± 3 mm |
| Housing design | Small, stainless steel |
| Light source | LED, RGB |
| Wave length | 470 nm, 525 nm, 625 nm |
| Light emission | Long side of housing |
| Light spot size | 1.6 mm x 9.5 mm |
| Light spot direction | Vertical |
| Teach-in mode | 2-point teach-in static/dynamic + proximity to markET: Teach-in dynamic |
| Supply voltage | 12 V DC ... 24 V DC |
| Ripple | β€ 5 Vpp |
| Current consumption | < 50 mA 3) |
| Switching frequency | 15 kHz 4) |
| Response time | 35 Β΅s 5) |
| Jitter | 15 Β΅s |
| Switching output | NPN |
| Switching output (voltage) | NPN: HIGH = approx. UV / LOW β€ 2 V |
| Output current Imax. | 50 mA 6) |
| Retention time (ET) | 28 ms, non-volatile memory |
| Time delay | None |
| Connection type | Cable with M12 male connector, 4-pin, 0.2 m; Cable with M12 male connector, 4-pin, 0.2 m |
| Protection class | III |
| Enclosure rating | IP69K |
| Weight | 40 g |
| Housing material | ABS |
| Optics material | PMMA |
| Ambient operating temperature | β30 Β°C ... +70 Β°C |
| Ambient temperature, storage | β30 Β°C ... +75 Β°C |
