Home Brands Sick Contrast Sensors KTM-LN55182P Sick KTM-LN55182P Contrast Sensor The Sick KTM-LN55182P Contrast Sensor offers Small, design β€ 250 mm sensing distance , 10 V DC ... 30 V DC supply voltage, NPN Output Cable with M12 male connector, 4-pin, 0.3 m; Cable with M12 male connector, 4-pin, 0.3 m connection . Manufactured by Sick under the Sick Contrast Sensor category, this model belongs to the KT Series.
Brand Sick Product Type Contrast Sensor Model Number KTM-LN55182P
Sick KTM-LN55182P Contrast Sensor β Technical Specifications Specification Value Dimensions (W x H x D) 12 mm x 31.5 mm x 21 mm Sensing distance β€ 250 mm Sensing distance tolerance Β± 30 mm Housing design Small Light source Laser, red Wave length 680 nm Light emission Long side of housing Light spot size Γ 1.8 mm (250 mm) Light spot direction Round Teach-in mode 2-point teach-in static/dynamic + proximity to markET: Teach-in dynamic Supply voltage 10 V DC ... 30 V DC Ripple β€ 5 Vpp Current consumption < 35 mA Switching frequency 1.5 kHz 3) Response time 333 Β΅s 4) Jitter 122 Β΅s Switching output NPN Switching output (voltage) NPN: HIGH = approx. UV / LOW β€ 2 V Output current Imax. 100 mA 5) Retention time (ET) 250 ms Time delay None Connection type Cable with M12 male connector, 4-pin, 0.3 m; Cable with M12 male connector, 4-pin, 0.3 m Protection class III Enclosure rating IP67 Weight Approx. 24 g Housing material ABS Optics material PMMA Ambient operating temperature β20 Β°C ... +50 Β°C Ambient temperature, storage β40 Β°C ... +70 Β°C
