Sick IQ40-40NNPKK0S Proximity Sensor
The Sick IQ40-40NNPKK0S Proximity Sensor offers a Rectangular; Standard design, 40 mm sensing range, Non-flush installation type, NPN Complementary output, and Cable gland connection. Manufactured by Sick under the Sick Proximity Sensor category, this model belongs to the IQ Series.
| Brand | Sick |
| Product Type | Proximity Sensor |
| Model Number | IQ40-40NNPKK0S |
Sick IQ40-40NNPKK0S Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Housing | Rectangular; Standard design |
| Sensing range Sn | 40 mm |
| Safe sensing range Sa | 32.4 mm |
| Installation type | Non-flush |
| Switching frequency | 100 Hz |
| Connection type | Cable gland |
| Switching output | NPN |
| Output function | Complementary |
| Electrical wiring | DC 4-wire |
| Enclosure rating | IP67, IP68, IP69K |
| Special applications | Difficult application conditions |
| Supply voltage | 10 V DC ... 30 V DC |
| Ripple | β€ 10 Vpp 1) |
| Voltage drop | β€ 2 V |
| Time delay before availability | β€ 200 ms |
| Hysteresis | 3 % ... 15 % 2) |
| Reproducibility | β€ 6 % |
| Temperature drift (of Sr) | Β± 10 % |
| Continuous current Ia | β€ 200 mA |
| No load current | 12.5 mA |
| Ambient operating temperature | β25 Β°C ... +85 Β°C |
| Housing material | Plastic, PA 66 |
| Sensing face material | Plastic, PA 66 |
| Tightening torque, max. | 1.8 Nm |
| Protection class | II 3) |
| Unit weight | 0.215 Kilograms |
| Net unit weight | 0.215 Kilograms |
| Country of origin | Malaysia |
