Sick IQ20-07BNSDP0S Proximity Sensor

The Sick IQ20-07BNSDP0S Proximity Sensor offers a Rectangular, 7 mm sensing range, Flush installation type, NPN NO output, and Cable with connector M8, 3-pin, 0.3 m connection. Manufactured by Sick under the Sick Proximity Sensor category, this model belongs to the IMS/IMP Series.

BrandSick
Product TypeProximity Sensor
Model NumberIQ20-07BNSDP0S

Sick IQ20-07BNSDP0S Proximity Sensor – Technical Specifications

SpecificationValue
HousingRectangular
Sensing range Sn7 mm
Safe sensing range Sa5.67 mm
Installation typeFlush
Switching frequency150 Hz
Connection typeCable with connector M8, 3-pin, 0.3 m
Switching outputNPN
Output functionNO
Electrical wiringDC 3-wire
Supply voltage10 V DC ... 30 V DC
Ripple≤ 10 % 1)
Voltage drop< 2.5 V 2)
Time delay before availability≤ 20 ms
Hysteresis1 % ... 15 %
Reproducibility± 5 % 3) 4)
Temperature drift (of Sr)± 10 %
Continuous current Ia≤ 200 mA
Ambient operating temperature–25 °C ... +70 °C
Housing materialZinc diecast, GD Zn
Sensing face materialPlastic, PA12
Cable materialPUR
