Home Sick Proximity Sensor IQ12-08NNOKT0S Sick IQ12-08NNOKT0S Proximity Sensor The Sick IQ12-08NNOKT0S Proximity Sensor offers a Rectangular , 8 mm sensing range, Non-flush installation type, NPN NC output, and Connector M8, 3-pin connection. Manufactured by Sick under the Sick Proximity Sensor category, this model belongs to the IMS/IMP Series.
Brand Sick Product Type Proximity Sensor Model Number IQ12-08NNOKT0S
Sick IQ12-08NNOKT0S Proximity Sensor โ Technical Specifications Specification Value Housing Rectangular Sensing range Sn 8 mm Safe sensing range Sa 6.48 mm Installation type Non-flush Switching frequency 2,000 Hz Connection type Connector M8, 3-pin Switching output NPN Output function NC Electrical wiring DC 3-wire Supply voltage 10 V DC ... 30 V DC Ripple โค 10 % 1) Voltage drop โค 3 V 2) Time delay before availability โค 100 ms Hysteresis 5 % ... 15 % Reproducibility โค 2 % 3) 4) Temperature drift (of Sr) ยฑ 10 % Continuous current Ia โค 200 mA No load current 10 mA Ambient operating temperature โ25 ยฐC ... +75 ยฐC Housing material Plastic, VISTALยฎ Sensing face material Plastic, VISTALยฎ Tightening torque, max. โค 1 Nm
