Home Sick Proximity Sensor IMP05-01BPSVR9S Sick IMP05-01BPSVR9S Proximity Sensor The Sick IMP05-01BPSVR9S Proximity Sensor offers a Metric , 1 mm sensing range, Flush installation type, PNP NO output, and Cable with connector M8, 3-pin, with knurled nuts, 0.3 m connection. Manufactured by Sick under the Sick Proximity Sensor category, this model belongs to the IMS/IMP Series.
Brand Sick Product Type Proximity Sensor Model Number IMP05-01BPSVR9S
Sick IMP05-01BPSVR9S Proximity Sensor – Technical Specifications Specification Value Housing Metric Thread size M5 x 0.5 Diameter Ø 5 mm Sensing range Sn 1 mm Safe sensing range Sa 0.8 mm Installation type Flush Switching frequency 1,000 Hz Connection type Cable with connector M8, 3-pin, with knurled nuts, 0.3 m Switching output PNP Output function NO Electrical wiring DC 3-wire Supply voltage 10 V DC ... 30 V DC Ripple ≤ 20 % 1) Voltage drop ≤ 2 V 2) Time delay before availability ≤ 30 ms Hysteresis 1 % ... 15 % 3) Reproducibility ≤ 5 % 4) 5) Temperature drift (of Sr) ± 10 % 6)± 15 % 7) Continuous current Ia ≤ 200 mA Ambient operating temperature –25 °C ... +100 °C Housing material Phynox, DIN 2.4711 Sensing face material Ceramics, ZrO2 Housing length 27 mm Thread length 5 mm Tightening torque, max. ≤ 5 Nm Cable material PUR Conductor size 0.14 mm²
