Sick IME2S12-04N4DC0S02 Proximity Sensor
The Sick IME2S12-04N4DC0S02 Proximity Sensor offers a Nickel-plated brass, 4 mm 1) sensing range, Non-flush installation type, output, and Male connector M12, 4-pin connection. Manufactured by Sick under the Sick Proximity Sensor category, this model belongs to the IM Series.
| Brand | Sick |
| Product Type | Proximity Sensor |
| Model Number | IME2S12-04N4DC0S02 |
Sick IME2S12-04N4DC0S02 Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Housing | Nickel-plated brass |
| Sensing range Sn | 4 mm 1) |
| Installation type | Non-flush |
| Connection type | Male connector M12, 4-pin |
| Enclosure rating | IP67 (IEC 60529) |
| Items supplied | Including mounting nuts, brass, nickel-plated (2x) |
| Ambient operating temperature | β25 Β°C ... +70 Β°C |
| Housing length | 65 mm |
| Thread length | 43 mm |
| Protection class | III (IEC 61140) |
| Unit weight | 47.000 Grams |
| Net unit weight | 47 Grams |
| Country of origin | Malaysia |
| Cable material | PVC |
| Cable diameter | 3.9 mm |
