Sick IM12-02BAS-ZU0 Proximity Sensor
The Sick IM12-02BAS-ZU0 Proximity Sensor offers a Metric; Standard design, 2 mm sensing range, Flush installation type, NO output, and Cable, 2-wire, 2 m connection. Manufactured by Sick under the Sick Proximity Sensor category, this model belongs to the IQ Series.
| Brand | Sick |
| Product Type | Proximity Sensor |
| Model Number | IM12-02BAS-ZU0 |
Sick IM12-02BAS-ZU0 Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Housing | Metric; Standard design |
| Thread size | M12 x 1 |
| Diameter | Γ 12 mm |
| Sensing range Sn | 2 mm |
| Safe sensing range Sa | 1.62 mm |
| Installation type | Flush |
| Switching frequency | 25 Hz |
| Connection type | Cable, 2-wire, 2 m |
| Output function | NO |
| Electrical wiring | AC 2-wire |
| Enclosure rating | IP67 1) |
| Items supplied | Mounting nut, brass, nickel-plated (2x) |
| Supply voltage | 20 V AC ... 250 V AC |
| Voltage drop | β€ 8.5 V 1) |
| Time delay before availability | β€ 10 ms |
| Hysteresis | 1 % ... 15 % |
| Reproducibility | β€ 10 % 2) 3) |
| Temperature drift (of Sr) | Β± 10 % |
| Continuous current Ia | β€ 250 mA 4)β€ 200 mA 5) |
| Ambient operating temperature | β25 Β°C ... +80 Β°C |
| Housing material | Brass, nickel-plated |
| Sensing face material | Plastic, PBT |
| Housing length | 71 mm |
| Thread length | 50 mm |
| Tightening torque, max. | β€ 7 Nm |
| Protection class | I |
| Unit weight | 0.118 Kilograms |
| Net unit weight | 0.118 Kilograms |
| Country of origin | Romania |
| Cable material | PUR/PVC |
| Conductor size | 0.5 mmΒ² |
