Sick DOL-1208-G05MAC1: Sensor Actuator Cable
Technical Specifications of Sick Sensor Actuator Cable DOL-1208-G05MAC1:
| Cable | 5 m, 8-wire, PUR, halogen-free |
| Cable diameter | 7 mm |
| Reference voltage | β€ 36 V AC/DC |
| Current loading | 2 A |
Sick Sensor Actuator Cable DOL-1208-G05MAC1 Technical Specifications
| Specification | Value |
|---|---|
| Connection type head A | Female connector, M12, 8-pin, straight |
| Connection type head B | Flying leads |
| Connector material | TPU |
| Connector color | Black |
| Cable | 5 m, 8-wire, PUR, halogen-free |
| Jacket material | PUR, halogen-free |
| Jacket color | Black |
| Cable diameter | 7 mm |
| Conductor cross section | 0.25 mmΒ², 4 x 2 x 0.25 mmΒ² |
| Shielding | Shielded |
| Reference voltage | β€ 36 V AC/DC |
| Current loading | 2 A |
| Signal type | Incremental, SSI |
| Operating temperature Flexible use | β25 Β°C ... +80 Β°C |
| Operating temperature Stationary position | β50 Β°C ... +80 Β°C |
| Operating temperature Head | β25 Β°C ... +90 Β°C |
