Sick DFS60B-S1PA10000 - Incremental Encoder
The Sick DFS60B-S1PA10000 incremental encoder provides 10,000 pulses per revolution with TTL/HTL output and a 6 mm solid shaft. It features a 6-channel architecture, supports 4.5β32 V supply, reaches 600 kHz output frequency, and maintains stable performance from β40 Β°C to +100 Β°C. This model belongs to the Sick automation lineup, is part of the Sick Incremental Encoder category, and aligns with the series widely used in industrial automation.
| Brand | Sick |
| Product Type | Incremental Encoder |
| Model Number | DFS60B-S1PA10000 |
Sick DFS60B-S1PA10000 Incremental Encoder - Technical Specifications
| Specification | Value |
|---|---|
| Pulses per revolution | 10,000 1) |
| Measuring step | 90Β°, electric/pulses per revolution |
| Error limits | Β± 0.05Β° |
| Communication interface | Incremental |
| Communication Interface detail | TTL / HTL |
| Factory setting | Factory setting: output level TTL |
| Number of signal channels | 6-channel |
| Initialization time | 32 ms, 30 ms 1) |
| Output frequency | β€ 600 kHz |
| Load current | β€ 30 mA |
| Power consumption | β€ 0.7 W (without load) |
| Connection type | Male connector, M23, 12-pin, radial |
| Supply voltage | 4.5 ... 32 V |
| Mechanical design | Solid shaft, Servo flange |
| Shaft diameter | 6 mmWith face |
| Shaft material | Stainless steel |
| Flange material | Aluminum |
| Housing material | Aluminum die cast |
| Start up torque | 0.5 Ncm (+20 Β°C) |
| Operating torque | 0.3 Ncm (+20 Β°C) |
| Operating speed | β€ 9,000 minβ»ΒΉ 1) |
| Moment of inertia of the rotor | 6.2 gcmΒ² |
| Bearing lifetime | 3.6 x 10^10 revolutions |
| Angular acceleration | β€ 500,000 rad/sΒ² |
| Operating temperature range | β40 Β°C ... +100 Β°C 2)β30 Β°C ... +100 Β°C 3) |
| Storage temperature range | β40 Β°C ... +100 Β°C, without package |
The Sick DFS60B-S1PA10000 incremental encoder delivers precise rotary measurement through its 10,000 PPR resolution, TTL/HTL interface, and reliable 6 mm solid shaft. As a member of the Sick DFS60 series, it uses a 6-channel signaling structure and operates within a 4.5β32 V supply range. This model is suitable for industrial automation environments that require accurate incremental feedback for stable machine operation.
The Sick DFS60B-S1PA10000 incremental encoder is used in conveyors, packaging equipment, assembly automation, and motion-control systems. Its high-resolution pulse output supports accurate shaft-speed and position tracking, while the TTL/HTL interface ensures compatibility with industrial controllers. The 6 mm solid shaft and servo flange design simplify installation in motor assemblies, and the aluminum die-cast housing provides durability for continuous-duty industrial applications.
The Sick DFS60B-S1PA10000 incremental encoder combines 10,000 PPR performance, a dependable TTL/HTL signal output, and a robust 6 mm solid shaft for consistent rotary sensing. As part of the DFS60 encoder family, it ensures long service life, stable measurement, and dependable operation across wide temperature conditions. Industrial users can rely on this Sick model for precise feedback, smooth integration, and reliable performance in demanding automation systems.
