Sick DFS60B-BHPK10000 - Incremental Encoder
Sick DFS60B-BHPK10000 incremental encoder provides 10,000 pulses per revolution, TTL/HTL output, blind hollow shaft, and 600 kHz frequency capability. This Sick Sick Encoder from the series supports 4.5–32 V supply voltage, 6-channel signals, cable 8-wire connection, ≤ 6,000 min⁻¹ operating speed, aluminum die-cast housing, stainless steel 15 mm blind hollow shaft, and –40 °C to +100 °C operating temperature range.
| Brand | Sick |
| Product Type | Incremental Encoder |
| Model Number | DFS60B-BHPK10000 |
Sick DFS60B-BHPK10000 Incremental Encoder - Technical Specifications
| Specification | Value |
|---|---|
| Pulses per revolution | 10,000 1) |
| Measuring step | 90°, electric/pulses per revolution |
| Error limits | ± 0.05° |
| Communication interface | Incremental |
| Communication Interface detail | TTL / HTL |
| Factory setting | Factory setting: output level TTL |
| Number of signal channels | 6-channel |
| Initialization time | 32 ms, 30 ms 1) |
| Output frequency | ≤ 600 kHz |
| Load current | ≤ 30 mA |
| Power consumption | ≤ 0.7 W (without load) |
| Connection type | Cable, 8-wire, universal, 1.5 m 1) |
| Supply voltage | 4.5 ... 32 V |
| Mechanical design | Blind hollow shaft |
| Shaft diameter | 15 mm |
| Shaft material | Stainless steel |
| Flange material | Aluminum |
| Housing material | Aluminum die cast |
| Start up torque | 0.8 Ncm (+20 °C) |
| Operating torque | 0.6 Ncm (+20 °C) |
| Operating speed | ≤ 6,000 min⁻¹ 1) |
| Moment of inertia of the rotor | 40 gcm² |
| Bearing lifetime | 3.6 x 10^10 revolutions |
| Angular acceleration | ≤ 500,000 rad/s² |
| Operating temperature range | –40 °C ... +100 °C 1)–30 °C ... +100 °C 2) |
| Storage temperature range | –40 °C ... +100 °C, without package |
The DFS60B-BHPK10000 incremental encoder is a Sick encoder designed for rotational feedback in industrial automation systems. This DFS60B-BHPK10000 incremental encoder delivers 10,000 pulses per revolution, TTL/HTL incremental signals, and a blind hollow shaft design for compact mechanical integration. Operating with ≤ 600 kHz output frequency and 4.5–32 V DC supply, it belongs to the DFS60 series and is used in encoder-based motion control applications.
The DFS60B-BHPK10000 incremental encoder is applied in conveyors, packaging machinery, automated assembly lines, and material handling systems. Its stable incremental output enables accurate speed monitoring and position tracking of rotating shafts. The blind hollow shaft construction supports space-efficient mounting, while the cable connection allows flexible installation in control cabinets and machine frames operating under continuous industrial duty cycles.
The Sick DFS60B-BHPK10000 incremental encoder combines defined electrical behavior with durable mechanical construction. With controlled torque values, long bearing lifetime, and aluminum housing, this incremental encoder supports reliable operation in demanding environments. As part of the DFS60 series from Sick, the DFS60B-BHPK10000 incremental encoder is suitable for industrial automation systems requiring consistent rotational measurement and long-term operational stability.
