Sick CSM-WP111C1P Color Sensor
The Sick CSM-WP111C1P color sensor provides ≤12.5 mm sensing distance, RGB LED light, PNP switching output, and IP67 enclosure protection. CSM-WP111C1P from Sick is a Sick Small RGB LED PNP Color Sensor featuring small housing design, 300 µs response time, 12–24 V DC supply, and 1 color output, listed under Sick Color Sensors within the CS Series.
| Brand | Sick |
| Product Type | Color Sensor |
| Product | CSM-WP111C1P |
Sick CSM-WP111C1P Color Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (W x H x D) | 12 mm x 31.5 mm x 21 mm |
| Sensing distance | ≤ 12.5 mm |
| Sensing distance tolerance | ± 3 mm |
| Housing design | Small |
| Light source | LED, RGB 1) |
| Wave length | 640 nm, 525 nm, 470 nm |
| Light spot size | 1.9 mm x 9.4 mm |
| Light spot direction | Vertical |
| Adjustment | Teach-in button |
| Output (channel) | 1 color |
| Supply voltage | 12 V DC ... 24 V DC 1) |
| Response time | 300 µs 5) |
| Switching output | PNP |
| Switching mode | Light/dark switching |
| Enclosure rating | IP67 |
| Ambient operating temperature | –10 °C ... +55 °C |
| Connection type | Male connector M8, 4-pin |
The CSM-WP111C1P Sick Small RGB LED PNP Color Sensor is a compact Color Sensor developed for precise short-range color detection in industrial automation. CSM-WP111C1P operates with a ≤12.5 mm sensing distance, an RGB LED light source, and a PNP switching output. It belongs to the CS Series and supports consistent color recognition in confined installations.
In industrial automation applications, the CSM-WP111C1P Sick Small RGB LED PNP Color Sensor is used in conveyors, packaging equipment, assembly lines, and inspection stations. Its small housing enables installation where space is limited, while teach-in adjustment simplifies setup. Stable output behavior supports reliable control in continuous production environments.
The Sick CSM-WP111C1P Color Sensor delivers dependable performance through its IP67 enclosure rating, standardized M8 connector, and defined operating temperature range. With predictable response characteristics and compact construction, CSM-WP111C1P meets industrial reliability requirements. As part of the CS Series from Sick, it integrates seamlessly into automation systems.
