Sick AFM60A-BHIB018X12 - Absolute Encoder
The Sick AFM60A-BHIB018X12 Absolute Encoder from the Sick ARS60 Series is a high-performance EtherNet/IP Absolute Encoder designed for industrial automation, motion control, and rotary feedback systems. It features a blind hollow shaft (15 mm) design, 262,144 steps per revolution (18-bit single-turn), and 4,096 revolutions (12-bit multi-turn), ensuring high positional precision. With a 10โ30V DC supply range, IP65/IP67-rated aluminum housing, and seamless EtherNet/IP connectivity, the AFM60A-BHIB018X12 delivers accurate, real-time feedback for machinery and process automation across industries in India.
| Brand | Sick |
| Product Type | Absolute Encoder |
| Model Number | AFM60A-BHIB018X12 |
Sick Absolute Encoder AFM60A-BHIB018X12 Technical Specifications
| Specification | Value |
|---|---|
| Number of steps per revolution (max. resolution) | 262,144 (18 bit) |
| Error limits G | 0.03ยฐ 1) |
| Repeatability standard deviation ฯr | 0.002ยฐ 2) |
| Communication interface | EtherNet/IPโข |
| Initialization time | 6 s |
| Connection type | Male connector, Female connector, 1x, 2x, M12, M12, 4-pin, 4-pin, axial, axial 1) 2) |
| Supply voltage | 10 ... 30 V |
| Mechanical design | Blind hollow shaft |
| Shaft diameter | 15 mm |
| Weight | 0.2 kg |
| Housing material | Aluminum |
| Start up torque | 0.8 Ncm (+20 ยฐC) |
| Operating torque | 0.6 Ncm (+20 ยฐC) |
| Permissible movement static | ยฑ 0.3 mm (radial)ยฑ 0.5 mm (axial) |
| Permissible movement dynamic | ยฑ 0.05 mm (radial)ยฑ 0.1 mm (axial) |
| Operating speed | โค 6,000 minโปยน 1) |
| Moment of inertia of the rotor | 40 gcmยฒ |
| Bearing lifetime | 3 x 10^9 revolutions |
| Angular acceleration | โค 500,000 rad/sยฒ |
| Enclosure rating | IP65, shaft side (IEC 60529)IP67, housing side (IEC 60529) 1) |
| Operating temperature range | โ40 ยฐC ... +85 ยฐC |
| Storage temperature range | โ40 ยฐC ... +100 ยฐC, without package |
| Permissible shaft loading | 60 N (radial)30 N (axial) |
| Number of revolutions | 4,096 (12 bit) |
| Power consumption | โค 3 W (without load) |
| Shaft material | Stainless steel |
| Flange material | Aluminum |
The Sick AFM60A-BHIB018X12 Absolute Encoder from the ARS60 Series provides high-resolution position measurement with 262,144 steps per revolution and 4,096 revolutions for multi-turn detection. Designed with a 15 mm blind hollow shaft and robust aluminum housing, it ensures efficient rotary feedback in demanding automation environments. Operating at up to 6,000 rpm with IP65/IP67 enclosure protection, this encoder combines mechanical strength with EtherNet/IP communication for precise, reliable signal transmission to PLCs and motion controllers.
In industrial automation and robotics, the AFM60A-BHIB018X12 Encoder plays a vital role in controlling conveyors, robotic arms, packaging machines, and material handling systems. Its EtherNet/IP interface allows seamless integration into networked automation systems for real-time position updates and diagnostic feedback. With a โ40ยฐC to +85ยฐC operating range and 3 ร 10โน bearing revolutions lifetime, it performs reliably even under vibration and temperature extremes. The encoderโs IP67-sealed housing protects against dust and moisture, making it ideal for continuous operation in harsh industrial settings where accuracy and uptime are critical.
Renowned for engineering precision, Sick remains one of the worldโs leading manufacturers of industrial sensing and automation solutions. The AFM60A-BHIB018X12 Absolute Encoder exemplifies this expertise, delivering long-term reliability, mechanical endurance, and electrical accuracy. Manufactured in ISO-certified facilities, it ensures consistent signal integrity, excellent repeatability (ฯr = 0.002ยฐ), and reduced downtime. Sickโs extensive global support network and commitment to innovation make it a trusted choice for OEMs, system integrators, and automation engineers seeking reliable rotary encoders for advanced machinery.
The Sick AFM60A-BHIB018X12 Absolute Encoder combines 18-bit EtherNet/IP communication, robust build quality, and precise feedback performance for advanced motion control applications. Its hollow shaft design, IP-rated durability, and proven service life make it a dependable solution for industrial automation projects in India. Engineers across sectors trust the AFM60A-BHIB018X12 Encoder for consistent accuracy, easy network integration, and reliable performance โ supported by the Sick service and support network
