Sick A3M60B-BHPB013X13 - Absolute Encoder
The Sick A3M60B-BHPB013X13 Absolute Encoder from the Sick ARS60 Series is a PROFIBUS DP multi-turn Absolute Encoder designed for industrial automation and precise position feedback applications. With 8,192 steps per revolution (13-bit single-turn) and 8,192 revolutions (13-bit multi-turn), it ensures high positional accuracy and reliable performance in motion control systems. Equipped with a 15 mm blind hollow shaft, IP65/IP67-rated aluminum housing, and 10β32V DC supply range, the A3M60B-BHPB013X13 provides efficient, consistent operation in conveyors, robotics, and packaging systems across India.
| Brand | Sick |
| Product Type | Absolute Encoder |
| Model Number | A3M60B-BHPB013X13 |
Sick Absolute Encoder A3M60B-BHPB013X13 Technical Specifications
| Specification | Value |
|---|---|
| Number of steps per revolution (max. resolution) | 8,192 (13 bit) |
| Error limits G | 0.5Β° (at room temperature) 1) |
| Repeatability standard deviation Οr | 0.25Β° (at room temperature) 2) |
| Communication interface | PROFIBUS DP |
| Initialization time | Approx. 1 s |
| Connection type | Male connector, Female connector, 2x, 1x, M12, M12, 5-pin, 5-pin, axial, axial |
| Supply voltage | 10 ... 32 V |
| Mechanical design | Blind hollow shaft |
| Shaft diameter | 15 mm |
| Weight | 0.28 kg |
| Housing material | Aluminum |
| Start up torque | 1 Ncm (+20 Β°C) |
| Operating torque | 0.8 Ncm (+20 Β°C) |
| Permissible movement static | Β± 0.3 mm (radial)Β± 0.5 mm (axial) |
| Permissible movement dynamic | Β± 0.1 mm (radial)Β± 0.2 mm (axial) |
| Operating speed | β€ 9,000 minβ»ΒΉ 1) |
| Bearing lifetime | 3.0 x 10^9 revolutions |
| Angular acceleration | β€ 500,000 rad/sΒ² |
| Enclosure rating | IP65, shaft side (IEC 60529)IP67, housing side (IEC 60529) 1) |
| Operating temperature range | β10 Β°C ... +70 Β°C |
| Storage temperature range | β40 Β°C ... +100 Β°C |
| Number of revolutions | 8,192 (13 bit) |
| Power consumption | β€ 1.5 W |
| Shaft material | Stainless steel |
| Flange material | Aluminum |
The Sick A3M60B-BHPB013X13 Absolute Encoder from the ARS60 Series combines 13-bit single-turn and 13-bit multi-turn resolution for accurate rotary position detection. Featuring a PROFIBUS DP interface, it ensures seamless data communication in networked automation systems. The 15 mm stainless-steel blind hollow shaft and IP67-rated aluminum housing offer superior resistance to environmental conditions, while its 9,000 rpm operating speed and bearing life of 3 Γ 10βΉ revolutions guarantee long-term stability. Engineered for precision and endurance, this encoder delivers smooth performance across demanding industrial automation setups.
In industrial automation and motion control, the A3M60B-BHPB013X13 Encoder is used in robotic arms, packaging machinery, conveyor systems, and servo drives where precise multi-turn feedback is required. Its PROFIBUS DP connectivity ensures fast and synchronized communication with PLCs for optimized motion accuracy. With operating temperatures from β10Β°C to +70Β°C and low torque design, it maintains dependable performance even in high-speed manufacturing environments. Engineers in India rely on this Absolute Encoder for maintaining consistent output and error-free machine positioning in production lines.
Globally trusted for innovation and reliability, Sick designs its ARS60 Series Absolute Encoders to meet strict ISO-certified manufacturing standards. The A3M60B-BHPB013X13 stands out for its robust construction, stainless-steel shaft, and low-maintenance operation. Its aluminum housing resists shock, vibration, and industrial contaminants, ensuring longevity in tough operating conditions. Supported by Sickβs worldwide service and engineering network, this encoder offers trusted performance for OEMs, automation integrators, and engineers seeking reliable rotary feedback across Indiaβs fast-growing industrial sector.
The Sick A3M60B-BHPB013X13 Absolute Encoder delivers precision, durability, and efficient PROFIBUS DP communication for accurate position feedback in automation systems. Its IP67 enclosure, multi-turn resolution, and mechanical endurance make it ideal for continuous industrial operation. Backed by Sickβs global support network, the A3M60B-BHPB013X13 Encoder remains a trusted choice for engineers and machine builders in India who require stable, high-accuracy performance in industrial automation and motion control.
