Selec PID110 Process PID Controller
The Selec PID110 Process PID Controller offers Relay or Current : 4 to 20mA DC (max load 500E) control output, Autotune PID / ON-OFF control mode, 90V to 270V AC/DC supply voltage, 96 x 48mm size, Panel Mount type. Manufactured by Selec under the Selec Process PID Controller category, this model belongs to the Selec PID Series.
| Brand | Selec |
| Product Type | Process PID Controller |
| Model Number | PID110 |
Selec PID110 Process PID Controller β Technical Specifications
| Specification | Value |
|---|---|
| Display Type | 7 Segment LED Dual Display |
| Display Configuration | 4+4 digits |
| Type of Inputs | Thermocouple: J, K, T, R, S, C, B, N, L, U, W, Platinel II RTD: pt100, Single Input (DC) -5 to 56mV, 0 to 10V, 0 to 20mA (Selectable) |
| Resolution | TC / RTD : 1/ 0.1 Analog input : 1 /0.1/ 0.01/ 0.001 |
| Accuracy | For TC (J, K, T) inputs: 0.25% of F.S. Β±1 For R & S inputs: 0.5% of F.S. Β±2 (20min of warm up time) For RTD inputs: 0.1% of F.S Β±1 |
| Control Output | Relay or Current : 4 to 20mA DC (max load 500E) |
| Auxiliary Output | Relay |
| Control Mode | Autotune PID / ON-OFF |
| Feature | Single step ramp soak |
| Supply Voltage | 90V to 270V AC/DC |
| Size | 96 x 48mm |
| Mounting Type | Panel Mount |
The Selec PID110 is a reliable Process PID Controller engineered for efficient and precise control of temperature, pressure, or flow processes. It features a 7-segment LED dual display with a 4+4 digit configuration, offering clear visibility of process and setpoint values in industrial environments. The standard 96 x 48 mm panel-mount size ensures seamless integration into compact control cabinets.
This controller supports universal input types, including Thermocouples (J, K, T, R, S, etc.), RTD PT100, and analog signals like -5 to 56mV, 0β10V, and 0β20mA. With selectable resolutions from 1 to 0.001, the PID110 adapts to both high-resolution and general-purpose control tasks. Accuracy is high across sensor types, with Β±0.1% F.S. for RTD and Β±0.25% F.S. for standard thermocouples. Control output is available in Relay or 4β20mA Current, and an Auxiliary Relay Output is included for alarm or secondary process triggering.
For process stability, the PID110 offers both Autotune PID and ON-OFF control modes. It also includes a Single Step Ramp Soak function for time-based temperature control. Operating on a wide 90β270V AC/DC input range, this controller performs reliably across voltage fluctuations common in industrial settings. For full integration details, refer to the official Selec Temperature Controller listing or explore all models on the Selec brand page.
Whether for small-scale machines or multi-zone process systems, the Selec PID110 Process PID Controller delivers consistent results with PID, Universal Input, Relay/Current Output, 96x48 mm control in PID110.
