Schneider TM241CE40R Programmable Logic Controller
TM241CE40R is a high-performance PLC from Schneider Electric, part of the Modicon M241 series, built for industrial automation with flexible relay and transistor outputs. Designed for scalable systems, it supports Ethernet, USB, and serial communications.
| Brand | Schneider |
| Product Type | Programmable Logic Controller (PLC) |
| Product | TM241CE40R |
Schneider TM241CE40R Programmable Logic Controller – Technical Specifications
| Specification | Value |
|---|---|
| Model | TM241CE40R |
| Manufacturer | Schneider Electric |
| Product Type | Programmable Logic Controller (PLC) |
| Series | Modicon TM241 |
| Power consumption in W | - |
| Output voltage limits | 125 V DC relay output30 V DC transistor output277 V AC relay output |
| Depth | 95 mm |
| Discrete input voltage type | DC |
| Maximum number of I/O expansion module | 7 (local I/O-Architecture)14 (remote I/O-Architecture) |
| Transmission rate | 1.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 15 m for RS4851.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 3 m for RS232480 Mbit/s for bus length of 3 m for USB10/100 Mbit/s for Ethernet |
| Range of product | Modicon M241 |
| Width | 190 mm |
| Backup time | 2 years at 25 °C |
| Reset time | 10 ms automatic reset output12 s automatic reset fast output |
| Height | 90 mm |
| Discrete output type | RelayTransistor |
| Discrete output current | 0.1 A for fast output (PTO mode) (TR0...TR3)2 A for relay output (Q4...Q15)0.5 A for transistor output (TR0...TR3) |
| Response time | 50 µs turn-on, I0...I15 terminal(s) for input |
| Discrete output number | 4 transistor 4 fast output12 relay |
| Discrete output logic | Positive logic (source) |
| Shock resistance | 15 gn for 11 ms |
| Protection type | Short-circuit protection for transistor outputShort-circuit and overload protection with automatic reset for transistor outputReverse polarity protection for transistor outputWithout protection for relay output |
| Supply voltage limits | 85…264 V |
| Discrete input number | 24, discrete input 8 fast input conforming to IEC 61131-2 Type 1 |
| Communication port protocol | Non isolated serial link: Modbus master/slave |
| Inrush current | - |
| Electrical connection | removable screw terminal blockfor inputs and outputs (pitch 5.08 mm) removable screw terminal blockfor connecting the 24 V DC power supply (pitch 5.08 mm) |
| Net weight | 0.62 kg |
| Operating altitude | 0...2000 m |
| Discrete input voltage | 24 V |
| Ambient air temperature for storage | -25…70 °C |
| Storage altitude | 0…3000 m |
| Discrete input logic | Sink or source |
| Pollution Degree | 2 |
| Insulation | Between supply and internal logic at 500 V ACNon-insulated between supply and ground |
The Schneider TM241CE40R is engineered to meet modern industrial control needs with its dual relay and transistor outputs. Supporting both sink and source input logic, this Modicon M241 PLC handles 24 discrete inputs (including 8 fast inputs) and delivers outputs across 12 relays and 4 fast transistor channels. It operates at 24 V DC input voltage, with output voltage limits reaching 30 V DC for transistor and up to 277 V AC for relay channels. Ideal for harsh environments, the TM241CE40R maintains performance across altitudes up to 2000 m and storage up to 3000 m.
The controller supports seamless integration via Modbus master/slave over RS232, RS485, Ethernet, and USB, with a compact 95 mm depth for tight enclosures. It is built with protection mechanisms such as short-circuit and overload protection (transistor outputs) and reverse polarity protection, ensuring operational reliability. The unit is rated for -25 to 70 °C storage temperature and conforms to IEC 61131-2 Type 1 input standards, making it a trusted choice for scalable automation systems.
