Schneider TM200C60R Programmable Logic Controller
The Schneider TM200C60R Programmable Logic Controller offers a 7 mA for input, 50 A current, Relay normally open output type. Manufactured by Schneider under the Schneider Programmable Logic Controller category, this model belongs to the TM Series.
| Brand | Schneider |
| Product Type | Programmable Logic Controller (PLC) |
| Model Number | TM200C60R |
Schneider TM200C60R Programmable Logic Controller – Technical Specifications
| Specification | Value |
|---|---|
| Protection type | - |
| Sensor power supply | 24 V DC at 300 mA supplied by the controller |
| Discrete input current | 7 mA for input |
| Ambient air temperature for operation | 0…55 °C (horizontal installation) |
| Power consumption in VA | 61…74 VA at 100...240 V AC (with max I/O) |
| Power consumption in W | - |
| Depth | 70 mm |
| Output frequency | - |
| [Us] rated supply voltage | 220 V AC |
| Discrete output number | 24 relay |
| Maximum voltage drop | - |
| Transmission rate | 1.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 15 m for RS4851.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 3 m for RS23212 Mbit/s for USB |
| Maximum cable distance between devices | Unshielded cable: <50 m for inputShielded cable: <10 m for fast inputShielded cable: <10 m for high speed inputUnshielded cable: <150 m for output |
| Communication port protocol | USB port: USB - SoMachine-NetworkNon isolated serial link: Modbus master/slave - RTU/ASCII or SoMachine-Network |
| Width | 225 mm |
| Output voltage limits | 30 V DC250 V AC |
| Net weight | 0.684 kg0.684 kg |
| Memory capacity | 512 byte internal flash for backup of programs |
| Supply voltage limits | 85…264 V |
| Discrete output current | 2 A |
| Discrete output logic | - |
| Electrical durability | 100000 cycles AC-12, 240 V, 480 VA, resistive100000 cycles DC-12, 24 V, 48 W, resistive |
| Discrete input voltage | 24 V |
| Maximum number of I/O expansion module | 4 with 128 discrete output(s) for transistor output4 with 88 discrete output(s) for relay output |
| Maximum current per output common | 4 A at COM 24 A at COM 04 A at COM 14 A at COM 34 A at COM 44 A at COM 5 |
| Inrush current | 50 A |
| Discrete output type | Relay normally open |
| Network frequency | - |
| Discrete input number | I2...I5: 4 fast inputI0, I1, I6, I7: 4 high speed inputI8...I35: 28 regular input |
| Ambient air temperature for storage | -25…70 °C |
| Electrical connection | Mini B USB 2.0 connectorfor a programming terminal removable screw terminal blockfor inputs removable screw terminal blockfor outputs removable screw terminal block, 4 terminal(s) for connecting the serial link1 removable screw terminal block, 3 terminal(s) for connecting the 100-240 V AC power supply |
The Schneider TM200C60R is part of the trusted Modicon M200 series PLC family, offering robust control with an extensive set of I/O options. It operates on a rated 220 V AC supply, with flexibility to handle input ranges from 85 to 264 V AC. Built for industrial-grade applications, the controller features 36 discrete inputs—including 4 high-speed inputs, 4 fast inputs, and 28 regular inputs—each supporting a 24 V input voltage and 7 mA current to ensure accurate signal processing across multiple control points.
For output, the TM200C60R delivers 24 relay outputs rated at 2 A per output, suitable for switching both 30 V DC and 250 V AC loads. It supports up to 4 A per output common across six COM terminals (COM 0 through COM 5), allowing for balanced distribution and high-demand load handling. With electrical durability rated at 100,000 switching cycles (AC-12 and DC-12), the PLC ensures longevity in mission-critical operations. An inrush current tolerance of 50 A further safeguards stability during startup sequences.
Designed for modern communication standards, this PLC supports USB 2.0, RS232, and RS485 ports, and is compatible with Modbus RTU/ASCII and SoMachine Network protocols. The device includes a 512-byte internal flash memory capable of storing up to 10,000 instructions, providing program retention even during power failures. With a compact form factor of 225 mm width and 70 mm depth, it fits efficiently into dense control cabinets. Operating within 0°C to 55°C, the Schneider TM200C60R stands out as a reliable automation backbone for large industrial environments.
