Schneider TM200C40T Programmable Logic Controller
The Schneider TM200C40T Programmable Logic Controller offers a 7 mA for input, 35 A current, Transistor output type. Manufactured by Schneider under the Schneider Programmable Logic Controller category, this model belongs to the TM Series.
| Brand | Schneider |
| Product Type | Programmable Logic Controller (PLC) |
| Model Number | TM200C40T |
Schneider TM200C40T Programmable Logic Controller – Technical Specifications
| Specification | Value |
|---|---|
| Protection type | Overload and short-circuit protection at 2 A |
| Sensor power supply | - |
| Discrete input current | 7 mA for input |
| Ambient air temperature for operation | 0…55 °C (horizontal installation) |
| Power consumption in VA | - |
| Power consumption in W | 18 W at 24 V DC (with max I/O) |
| Depth | 70 mm |
| Output frequency | 100 kHz for fast output (PWM/PLS mode) at Q0...Q1 |
| [Us] rated supply voltage | 24 V DC |
| Discrete output number | Q0...Q1: 2 fast output (PLS/PWM/PTO mode)Q2...Q15: 14 transistor output |
| Maximum voltage drop | <1 V |
| Transmission rate | 1.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 15 m for RS4851.2...115.2 kbit/s (115.2 kbit/s by default) for bus length of 3 m for RS23212 Mbit/s for USB |
| Maximum cable distance between devices | Unshielded cable: <50 m for inputShielded cable: <10 m for fast inputShielded cable: <10 m for high speed inputUnshielded cable: <150 m for output |
| Communication port protocol | USB port: USB - SoMachine-NetworkNon isolated serial link: Modbus master/slave - RTU/ASCII or SoMachine-Network |
| Width | 175 mm |
| Output voltage limits | - |
| Net weight | 0.522 kg |
| Memory capacity | 512 byte internal flash for backup of programs |
| Supply voltage limits | 20.4…28.8 V |
| Discrete output current | 0.5 A |
| Discrete output logic | Positive logic (source) |
| Electrical durability | - |
| Discrete input voltage | 24 V |
| Maximum number of I/O expansion module | 4 with 64 discrete output(s) for relay output4 with 144 discrete output(s) for transistor output |
| Maximum current per output common | 2 A at COM 02 A at COM 14 A at COM 2 |
| Inrush current | 35 A |
| Discrete output type | Transistor |
| Network frequency | - |
| Discrete input number | I2...I5: 4 fast inputI0, I1, I6, I7: 4 high speed inputI8...I23: 16 regular input |
| Ambient air temperature for storage | -25…70 °C |
| Electrical connection | Mini B USB 2.0 connectorfor a programming terminal removable screw terminal blockfor inputs removable screw terminal blockfor outputs removable screw terminal block, 3 terminal(s) for connecting the 24 V DC power supply removable screw terminal block, 4 terminal(s) for connecting the serial link1 |
The Schneider TM200C40T is a powerful PLC in the M200 series, engineered to deliver fast, precise control in high I/O environments. It runs on a 24 V DC power supply with voltage limits from 20.4 to 28.8 V and consumes 18 W under full I/O load, ensuring energy efficiency across applications. This controller offers 24 discrete inputs, including 4 high-speed inputs, 4 fast inputs, and 16 regular inputs, all supporting a 24 V input voltage and 7 mA current. It includes 16 transistor outputs, with Q0–Q1 supporting high-speed PWM, PLS, and PTO modes at up to 100 kHz, and Q2–Q15 as standard outputs rated at 0.5 A each.
Output current handling is divided across COM 0, COM 1, and COM 2 terminals, with a maximum of 2 A for COM 0 and COM 1, and up to 4 A for COM 2, allowing balanced power distribution for demanding tasks. The inrush current capacity of 35 A ensures safe power-on behavior, while overload and short-circuit protection at 2 A protects your system hardware. This PLC includes 512 bytes of internal flash memory for program backup up to 10,000 instructions, ensuring uninterrupted operation even in power failure scenarios.
Designed for seamless communication, the TM200C40T supports USB 2.0, RS232, and RS485 ports, along with compatibility for Modbus RTU/ASCII and SoMachine Network protocols. The compact footprint of 175 mm width and 70 mm depth allows efficient panel integration. It operates reliably in ambient conditions between 0°C to 55°C and stores safely down to –25°C. Built for flexibility, speed, and safety, the Schneider TM200C40T is a trusted solution for modern industrial automation.
