GZ1E08: Schneider GZ1 3 pole 2.5-4A breaker
Technical Specifications of Schneider GZ1 3 pole 2.5-4A breaker GZ1E08:
| Mounting Support | Rail |
| Power Dissipation | 2.5 W (per pole) |
| Mounting Mode | By clipsBy screws |
| Connections Terminals | Screw clamp terminals 2 1…6 mm² - cable stiffness: solidScrew clamp terminals 2 1.5…6 mm² - cable stiffness: flexible without cable endScrew clamp terminals 2 1…4 mm² - cable stiffness: flexible with cable end |
Schneider GZ1 3 pole 2.5-4A breaker GZ1E08 Technical Specifications:
| Specification | Value |
|---|---|
| Device application | Motor |
| mounting position | Any position |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-2 |
| Ambient air temperature for operation | -20…60 °C |
| Mounting support | Rail |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| Electrical durability | 100000 cycles for AC-3 |
| Range | Easy TeSys |
| Magnetic tripping current | 51 A |
| Product or component type | Circuit breaker |
| poles description | 3P |
| Width | 44.5 mm |
| Control type | Push-button |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Colour | Grey (RAL 7011) |
| Power dissipation | 2.5 W (per pole) |
| mounting mode | By clipsBy screws |
| Operating altitude | 2000 m |
| Fire resistance | 960 °C conforming to IEC 60695-2-1 |
| Thermal protection adjustment range | 2.5…4 A |
| Net weight | 0.26 kg |
| Motor power kW | 0.75 kW at 230 V AC 50/60 Hz1.5 kW at 400 V AC 50/60 Hz1.5 kW at 440 V AC 50/60 Hz2.2 kW at 500 V AC 50/60 Hz3 kW at 690 V AC 50/60 Hz |
| Network type | AC |
| [Ui] rated insulation voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| Device short name | GZ1E |
| Utilisation category | AC-3 |
| Maximum operating rate | 25 cyc/h |
| Range of product | Easy TeSys Power |
| Ambient air temperature for storage | -40…80 °C |
| Network frequency | 50/60 Hz conforming to IEC 60947-2 |
| Depth | 78 mm |
| Trip unit technology | Thermal-magnetic |
| Height | 89 mm |
| Connections - terminals | Screw clamp terminals 2 1…6 mm² - cable stiffness: solidScrew clamp terminals 2 1.5…6 mm² - cable stiffness: flexible without cable endScrew clamp terminals 2 1…4 mm² - cable stiffness: flexible with cable end |
IndMALL Automation Dealing offers Schneider GZ1 3 pole 2.5-4A breaker GZ1E08 at unbeatable prices. The Main Technical Parameters of GZ1E08 are Motor applications, suitable for installation in Any position. It has a rated impulse to withstand voltage [Uimp] of 6 kV conforming to IEC 60947-2 standards, ensuring robust protection. The sensor operates efficiently in ambient temperatures ranging from -20…60 °C and can be mounted on a Rail for flexible installation. Its rated operational voltage [Ue] is 690 V AC 50/60 Hz conforming to IEC 60947-2, providing reliable power handling. With the electrical durability of 100000 cycles for AC-3 applications, this sensor ensures long-lasting performance. The magnetic tripping current is set at 51 A, and it features a 3P configuration. Control is managed through a convenient Push-button interface. Take the First Step with a Quote for your requirement of Schneider GZ1 3 pole 2.5-4A breaker. Choose us for unparalleled pricing and support over other Dealers & Distributors.
