GZ1E03: Schneider GZ1 0.25-0.40A Circuit Breaker

Technical Specifications of Schneider GZ1 0.25-0.40A Circuit Breaker GZ1E03:

Mounting Support	Rail
Power Dissipation	2.5 W (per pole)
Mounting Mode	By clipsBy screws
Connections Terminals	Screw clamp terminals 2 1…6 mm² - cable stiffness: solidScrew clamp terminals 2 1.5…6 mm² - cable stiffness: flexible without cable endScrew clamp terminals 2 1…4 mm² - cable stiffness: flexible with cable end

Schneider GZ1 0.25-0.40A Circuit Breaker GZ1E03 Technical Specifications:

Specification	Value
Device application	Motor
mounting position	Any position
[Uimp] rated impulse withstand voltage	6 kV conforming to IEC 60947-2
Ambient air temperature for operation	-20…60 °C
Mounting support	Rail
[Ue] rated operational voltage	690 V AC 50/60 Hz conforming to IEC 60947-2
Electrical durability	100000 cycles for AC-3
Range	Easy TeSys
Magnetic tripping current	5 A
Product or component type	Circuit breaker
poles description	3P
Width	44.5 mm
Control type	Push-button
IP degree of protection	IP20 conforming to IEC 60529
Colour	Grey (RAL 7011)
Power dissipation	2.5 W (per pole)
mounting mode	By clipsBy screws
Operating altitude	2000 m
Fire resistance	960 °C conforming to IEC 60695-2-1
Thermal protection adjustment range	0.25…0.4 A
Net weight	0.26 kg
Motor power kW	-
Network type	AC
[Ui] rated insulation voltage	690 V AC 50/60 Hz conforming to IEC 60947-2
Device short name	GZ1E
Utilisation category	AC-3
Maximum operating rate	25 cyc/h
Range of product	Easy TeSys Power
Ambient air temperature for storage	-40…80 °C
Network frequency	50/60 Hz conforming to IEC 60947-2
Depth	78 mm
Trip unit technology	Thermal-magnetic
Height	89 mm
Connections - terminals	Screw clamp terminals 2 1…6 mm² - cable stiffness: solidScrew clamp terminals 2 1.5…6 mm² - cable stiffness: flexible without cable endScrew clamp terminals 2 1…4 mm² - cable stiffness: flexible with cable end

Ask for the Pricing of Schneider GZ1 0.25-0.40A Circuit Breaker GZ1E03 at unbeatable prices. Detailed Specifications of GZ1E03 features Motor applications, suitable for installation in Any position. It has a rated impulse to withstand voltage [Uimp] of 6 kV conforming to IEC 60947-2 standards, ensuring robust protection. The sensor operates efficiently in ambient temperatures ranging from -20…60 °C and can be mounted on a Rail for flexible installation. Its rated operational voltage [Ue] is 690 V AC 50/60 Hz conforming to IEC 60947-2, providing reliable power handling. With the electrical durability of 100000 cycles for AC-3 applications, this sensor ensures long-lasting performance. The magnetic tripping current is set at 5 A, and it features a 3P configuration. Now's the Time to Secure a Quote for your requirement of Schneider GZ1 0.25-0.40A Circuit Breaker. We're committed to offering more favorable pricing and more responsive support than other Traders.
