Schneider ATV310HU15N4E Variable Speed Drive
The Schneider ATV310HU15N4E is a robust 2HP VFD from the trusted Altivar 310 range, engineered to deliver precision motor control in demanding industrial automation systems.
| Brand | Schneider |
| Product Type | VFD - Variable Frequency Drive |
| Model Number | ATV310HU15N4E |
Schneider ATV310HU15N4E Variable Speed Drive – Technical Specifications
| Specification | Value |
|---|---|
| Minimum switching current | 5 mA at 24 V DC for logic relay |
| Analogue output number | 1 |
| Height | 143 mm |
| Speed drive output frequency | 0.5…400 Hz |
| Unit Type of Package 2 | S03 |
| Time constant | 20 ms +/- 1 ms for reference change |
| Operating altitude | <= 1000 m without derating |
| Number of addresses | 1…247 for Modbus |
| Supply frequency | 50/60 Hz +/- 5 % |
| Device short name | ATV310 |
| Acceleration and deceleration ramps | Linear from 0...999.9 sSU |
| Speed range | 1…20 for asynchronous motor |
| Physical interface | 2-wire RS 485 for Modbus |
| Product or component type | Variable speed drive |
| Ambient air temperature for storage | -25…70 °C |
| Analogue input number | 1 |
| Output voltage | 380...460 V three phase |
| Continuous output current | 4.1 A heavy duty |
| Package 2 Weight | 5.253 kg |
| Asynchronous motor control profile | Voltage/frequency ratio (V/f)Voltage/frequency ratio - Energy Saving, quadratic U/fSensorless vector control (SVC) |
| Electrical connection | Terminal, clamping capacity: 1.5...2.5 mm², AWG 16...AWG 14 (L1, L2, L3, PA/+, PB, U, V, W) |
| Maximum switching current | 2 A at 250 V AC on inductive load cos phi = 0.4 L/R = 7 ms for logic relay2 A at 30 V DC on inductive load cos phi = 0.4 L/R = 7 ms for logic relay3 A at 250 V AC on resistive load cos phi = 1 L/R = 0 ms for logic relay4 A at 30 V DC on resistive load cos phi = 1 L/R = 0 ms for logic relay |
| Electromagnetic compatibility | Electrical fast transient/burst immunity test - test level: level 4 conforming to IEC 61000-4-4Electrostatic discharge immunity test - test level: level 3 conforming to IEC 61000-4-2Immunity to conducted disturbances - test level: level 3 conforming to IEC 61000-4-6Radiated radio-frequency electromagnetic field immunity test - test level: level 3 conforming to IEC 61000-4-3Voltage dips and interruptions immunity test conforming to IEC 61000-4-11Surge immunity test - test level: level 3 conforming to IEC 61000-4-5 |
| Motor slip compensation | Adjustable |
| Supply | Internal supply for reference potentiometer: 5 V (4.75…5.25 V)DC, <10 mA with overload and short-circuit protectionInternal supply for logic inputs: 24 V (20.4…28.8 V)DC, <100 mA with overload and short-circuit protection |
| Braking torque | Up to 150 % of nominal motor torque with braking resistorUp to 70 % of nominal motor torque without braking resistor |
| Number of Units in Package 1 | 1 |
| Width | 105 mm |
| Package 1 Weight | 1.380 kg |
| Range of product | Easy Altivar 310 |
| Depth | 151 mm |
| Operating position | Vertical +/- 10 degree |
| Pollution degree | 2 conforming to IEC 61800-5-1 |
| Communication service | Read holding registers (03) 29 wordsWrite single register (06) 29 wordsWrite multiple registers (16) 27 wordsRead/write multiple registers (23) 4/4 wordsRead device identification (43) |
| Quantity per set | Set of 1 |
The ATV310HU15N4E from Schneider is a compact VFD (Variable Frequency Drive) designed to deliver efficient motor control for industrial automation. As part of the trusted Easy Altivar 310 series, this Schneider 2HP VFD offers reliable performance, energy savings, and ease of integration for engineers and maintenance teams across industries.
The Schneider 2HP VFD ATV310HU15N4E is engineered with a wide output frequency range of 0.5–400 Hz, allowing smooth and precise speed control of asynchronous motors. It supports a continuous output current of 4.1 A at 380–460 V three-phase, making it ideal for heavy-duty cycles. The drive integrates advanced motor control modes such as V/f ratio, quadratic U/f, and Sensorless Vector Control (SVC), ensuring optimal torque and efficiency in dynamic load conditions. Designed for durability, it withstands storage temperatures between -25 °C and 70 °C and operating altitudes up to 1000 m without derating. With EMC compliance to IEC 61000 standards, the ATV310HU15N4E Schneider remains stable in electrically noisy environments. Its compact build (143 mm height × 105 mm width × 151 mm depth) ensures easy panel fitting, while safety is reinforced with overload and short-circuit protection on both inputs and logic relays.
The ATV310HU15N4E is widely applied in industries where variable speed control is critical to operational efficiency. In HVAC systems, it regulates fans and pumps for energy savings. In manufacturing, it ensures smooth conveyor belt automation, while in food and chemical plants it provides precise mixer speed adjustments. Textile machinery and bottling lines benefit from its quiet operation and stable performance, reducing downtime and mechanical wear. For both junior and senior maintenance engineers, the Schneider 2HP VFD simplifies retrofitting and commissioning, while engineering students gain practical insights into modern motor control through its versatile design.
For engineers looking up the ATV310HU15N4E datasheet, the Schneider ATV310HU15N4E stands out as a reliable and proven 2HP VFD solution. By combining high-performance motor control with user-friendly features, the ATV310HU15N4E Schneider drive has become a preferred choice across Indian industries. Whether you are upgrading an existing panel or commissioning new equipment, this model ensures reliability, flexibility, and energy efficiency, making the Schneider 2HP VFD ATV310HU15N4E an essential drive for long-term industrial success.
