Schneider ATV12H018M2 Variable Speed Drive
The Schneider ATV12H018M2 Variable Speed Drive offers a 0.25 hp motor power, 0.18 kW motor power, Cabinet mount and 1 RJ45 connector type. Manufactured by Schneider under the Schneider Variable Speed Drive category, this model belongs to the Altistart12 Series.
| Brand | Schneider Electric |
| Product Type | Variable Speed Drive |
| Product | ATV12H018M2 |
Schneider ATV12H018M2 Variable Speed Drive – Technical Specifications
| Specification | Value |
|---|---|
| Ambient air temperature for storage | -25…70 °C |
| Motor power hp | 0.25 hp |
| Connector type | 1 RJ45 |
| Operating position | Vertical +/- 10 degree |
| Vibration resistance | 1 gn (f = 13…200 Hz) conforming to IEC 60068-2-61.5 mm peak to peak (f = 3…13 Hz) - drive unmounted on symmetrical DIN rail - conforming to IEC 60068-2-6 |
| Continuous output current | 1.4 A at 4 kHz |
| EMC filter | Integrated |
| Ambient air temperature for operation | -10…40 °C without derating40…60 °C with current derating 2.2 % per °C |
| Switching frequency | 2...16 kHz adjustable4...16 kHz with derating factor |
| Motor power kW | 0.18 kW |
| Discrete output number | 2 |
| Nominal switching frequency | 4 kHz |
| Height | 143 mm |
| Tightening torque | 0.8 N.m |
| Maximum output frequency | 4 kHz |
| Maximum output voltage | 240 V |
| Supply frequency | 50/60 Hz +/- 5 % |
| IP degree of protection | IP20 |
| Physical interface | 2-wire RS 485 |
| Pollution degree | 2 |
| Mounting mode | Cabinet mount |
| Speed drive output frequency | 0.5…400 Hz |
| Network frequency | 50...60 Hz |
| Net weight | 0.7 kg |
| Analogue output number | 1 |
| Range of product | Altivar 12 |
| Nominal output current | 1.4 A |
| Product or component type | Variable speed drive |
| [Us] rated supply voltage | 200...240 V - 15...10 % |
| Power dissipation in W | Natural: 18.0 W |
ATV12H018M2 from Schneider Electric is a compact 0.18kW 1 Phase Variable Speed Drive designed for reliable and energy-efficient motor control. Part of the Altivar 12 series, this VFD is engineered for small machinery, fans, and pumps, helping industrial buyers and OEMs achieve precision automation with trusted Schneider quality.
The Schneider ATV12H018M2 delivers consistent performance with a motor power of 0.18 kW (0.25 HP) and a nominal output current of 1.4 A. It supports a wide output frequency range of 0.5–400 Hz, ensuring smooth and precise motor speed control. Built with a rated supply voltage of 200–240 V single-phase, the drive provides maximum output voltage up to 240 V and integrates an EMC filter for reduced interference. Its adjustable switching frequency of 2–16 kHz enhances flexibility in different setups, while the 2-wire RS485 interface ensures seamless Modbus communication with other automation systems. Compact in design, it measures only 143 mm in height and weighs just 0.7 kg, making it suitable for cabinet-mount applications. Designed for durability, it operates reliably from -10 °C to 40 °C without derating and up to 60 °C with a 2.2% derating per °C. Compliance with IEC vibration standards, IP20 protection, and robust build quality further confirm why the ATV12H018M2 Schneider Electric is a trusted choice in industrial environments.
Applications of the ATV12H018M2 are most commonly seen in fans, pumps, small conveyors, and light machinery where compact yet efficient drives are required. For Indian maintenance engineers, it provides reliable performance in HVAC systems, small packaging lines, and laboratory equipment where precise motor speed control directly improves productivity and energy savings. Its Modbus compatibility allows easy integration with building automation and SCADA systems, making it suitable for both industrial and commercial projects. The Schneider 0.18kW 1 Phase Variable Speed Drive is therefore not only cost-effective but also future-ready for scalable automation needs.
When evaluating this model, buyers often search for resources such as the ATV12H018M2 manual, ATV12H018M2 datasheet, and updated ATV12H018M2 price. Popular queries also include variations like atv12h018m2 Schneider Electric, schneider atv12h018m2, and atv12ho18m2. With its compact design, robust technical capabilities, and global trust of Schneider Electric, the ATV12H018M2 remains one of the most reliable VFD solutions for precise motor control.
