Schmersal ZFH 232-11 Foot Switch
The Schmersal ZFH 232-11 Foot Switch (Item No: 101181541) offers a 1,000,000 Operations mechanical life, minimum, Screw terminals M20 x 1.5termination, NO contact, NC contact switching element, Snap action switching principle. Manufactured by Schmersal under the Schmersal Foot Switch. category, this model belongs to the Schmersal ZFH Series.
| Brand | Schmersal |
| Product Type | Foot Switch |
| Model Number | ZFH 232-11 |
Schmersal ZFH 232-11 Foot Switch β Technical Specifications
| Specification | Value |
|---|---|
| Housing material | Aluminium |
| Housing coating material | powder-coated |
| Material of the housing cover | Aluminium |
| Material of the pedal | Glass-fibre, reinforced thermoplastic |
| Material of the protective shield | Aluminium |
| Colour of the housing | RAL 9006 (White aluminum) |
| Gross weight | 1,700 g |
| Protective shield | Yes |
| Probing possible | Yes |
| Number of normally closed (NC) | 1 |
| Number of normally open (NO) | 1 |
| Mechanical life, minimum | 1,000,000 Operations |
| Termination | Screw terminals M20 x 1.5 |
| Cable section, maximum | 1 x 2.5 mmΒ² |
| Width | 170 mm |
| Height | 189 mm |
| Depth | 274 mm |
| Degree of protection | IP65 |
| Ambient temperature | -25 ... +70 Β°C |
| Rated insulation voltage Ui | 500 V |
| Rated impulse withstand voltage Uimp | 6 kV |
| Thermal test current | 10 A |
| Utilisation category AC-15 | 4 A |
| Utilisation category DC-13 | 1 A |
| Switching element | NO contact, NC contact |
| Switching principle | Snap action |
Get A Quote for Schmersal Foot switch ZFH 232-11 Item No: 101181541 at the best price. Here are the brief Technical Specifications of ZFH 232-11, 101181541 are Aluminium housing and a pedal made from Glass-fibre, reinforced thermoplastic, ensuring long-lasting durability. The housing is finished in RAL 9006 (White aluminum), giving it a clean, professional look. With a mechanical life of over 1,000,000 Operations, it guarantees reliable performance over time. The switch is used for easy and secure wiring and supports a termination via Screw terminals M20 x 1.5 cable entry. Its dimensions include a width of 170 mm, height of 189 mm, and depth of 274 mm. Built for tough environments, it holds an IP65 degree of protection and operates within an ambient temperature range of -25 ... +70 Β°C. It features both NO contact, NC contact with an Snap action switching principle. It's Time to get a Quote for your requirement of Foot switch ZFH 232-11. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
