Schmersal UV7H 434Y-S1+OE3 Limit Switch
The Schmersal UV7H 434Y-S1+OE3 Limit Switch (Item No: 101060639) offers a mechanical working principle, 10,000,000 Operationsmechanical life, minimum, Screw terminals M20 x 1.5 termination, IP65 degree of protection. Manufactured by Schmersal under the Schmersal Limit Switch. category, this model belongs to the Schmersal TV Series.
| Brand | Schmersal |
| Product Type | Limit Switch |
| Model Number | UV7H 434Y-S1+OE3 |
Schmersal UV7H 434Y-S1+OE3 Limit Switch β Technical Specifications
| Specification | Value |
|---|---|
| Working principle | mechanical |
| Slide form | Castor |
| Housing material | Light alloy die-casting |
| Housing coating material | painted |
| Gross weight | - |
| Number of normally closed (NC) | 3 |
| Number of normally open (NO) | 1 |
| Actuating element | Roller lever |
| Roller material | Plastic |
| Mechanical life, minimum | 10,000,000 Operations |
| Actuating angle, from left of switch axis | 30 Β° |
| Actuating angle, from right of switch axis | 30 Β° |
| Contact opening | 2 x 1.5 mm |
| Actuating speed, minimum | 1 mm/min |
| Actuating speed, maximum | 3 m/s |
| Termination | Screw terminals M20 x 1.5 |
| Cable section, maximum | 2.5 mmΒ² |
| Connection technique - Wire cross-section | 13 AWG |
| Length of sensor | 50 mm |
| Width of sensor | 62 mm |
| Height of sensor | 262 mm |
| Width of Castor | 9 mm |
| Diameter of Castor | 36 mm |
| Degree of protection | IP65 |
| Ambient temperature | -20 ... +60 Β°C |
| Rated insulation voltage Ui | 500 V |
| Thermal test current | 16 A |
| Utilisation category AC-15 | - |
| Switching element | NC contact NO contact |
| Switching principle | Slow action |
| Material of the contacts, electrical | Silver |
Ask for the Pricing of Medium-duty position switches UV7H 434Y-S1+OE3 part no: 101060639 at unbeatable prices. Detailed Specifications of UV7H 434Y-S1+OE3, 101060639 feature Light alloy die-casting, ensuring durability in industrial environments. The switch features a Roller lever actuating element, providing precise mechanical operation. With a gross weight of -, it maintains a compact yet robust design. The connection technique supports 13 AWG wire cross-section, ensuring reliable electrical connections. Dimensions include a sensor length of 50 mm, width of 62 mm, and height of 262 mm. The castor width is 9 mm, with a diameter of 36 mm, enhancing mechanical efficiency. The unit is rated IP65, offering protection against dust and water ingress. Designed for high-voltage applications, it features a rated insulation voltage (Ui) of 500 V, ensuring electrical safety. Now's the Time to Secure a Quote for your requirement of Medium-duty position switches . We're committed to offering more favorable pricing and more responsive support than other Traders.
