Schmersal TQ 700-02 Pull-wire Switches
The Schmersal TQ 700-02 Pull-wire Switches (Item No: 131192480) offers a 1,000,000 Operations mechanical life, minimum, IP67 degree of protection, 500 V rated insulation voltage Ui, Opener (NC) switching element. Manufactured by Schmersal under the Schmersal Pull-wire Switches. category, this model belongs to the Schmersal TQ Series.
| Brand | Schmersal |
| Product Type | Pull-wire switch |
| Model Number | TQ 700-02 |
Schmersal TQ 700-02 Pull-wire Switches – Technical Specifications
| Specification | Value |
|---|---|
| Housing material | Glass fibre, thermoplastic |
| Length of the wire, maximum | 10 m |
| Gross weight | 230 g |
| Mechanical life, minimum | 1,000,000 Operations |
| Termination | Screw terminals M20 x 1.5 |
| Cable section, minimum | 0.75 mm² |
| Cable section, maximum | 2.5 mm² |
| Width | 40.5 mm |
| Height | 160 mm |
| Degree of protection | IP67 |
| Ambient temperature | 25 ... +70 °C |
| Rated insulation voltage Ui | 500 V |
| Rated impulse withstand voltage Uimp | 6 kV |
| Thermal test current | 10:00 AM |
| Utilisation category AC 15 | 4:00 AM |
| Utilisation category DC 13 | 4:00 AM |
| Switching element | Opener (NC) |
| Material of the contacts, electrical | Silver |
| Material of the housing cover | Glass fibre, thermoplastic |
| Number of normally closed (NC) | 2 |
| Standards | EN ISO 13849 1 |
| Mission time | 20 Year(s) |
| Switching principle | Slow action |
| Depth | 42.2 mm |
Mail Us for your needs in Schmersal Pull-wire Switches TQ 700-02 Item No: 131192480 with budget-friendly prices. The Main Technical Parameters of TQ 700-02, 131192480 include Glass fibre, thermoplastic housing, this switch ensures durability even in harsh industrial environments. It boasts a mechanical life of over 1,000,000 Operations, making it ideal for long-term use in safety-critical systems. Termination is via Screw terminals M20 x 1.5 entry, allowing for easy and secure wiring. The rated insulation voltage is 500 V, with a rated impulse withstand voltage of 6 kV, ensuring safe electrical performance. The switching element includes Opener (NC) for reliable signal handling. Weighing 230 g, this switch maintains a compact and sturdy form. It is protected with IP67 ratings, offering excellent resistance to dust and water ingress. Customize Your Experience with a Quote for your requirement of 25 ... +70 °C. Experience the difference with our competitive pricing and superior support over other Suppliers.
