Schmersal TKF/9024VDC Solenoid Interlocks
The Schmersal TKF/9024VDC Solenoid Interlocks (Item No: 101010237) offers a electromechanical working principle, Screw terminalstermination, IP67 degree of protection, 400 V rated insulation voltage Ui. Manufactured by Schmersal under the Schmersal Solenoid Interlocks. category, this model belongs to the Schmersal TKF Series.
| Brand | Schmersal |
| Product Type | Solenoid Interlocks |
| Model Number | TKF/9024VDC |
Schmersal TKF/9024VDC Solenoid Interlocks β Technical Specifications
| Specification | Value |
|---|---|
| Coding level according to EN ISO 14119 | Low |
| Working principle | electromechanical |
| Housing material | Aluminium |
| Gross weight | 1,472 g |
| Holding force FZhin accordance with EN ISO 14119 | 3,000 N |
| Latching force | 20 N |
| Positive break force, minimum | 20 N |
| Actuating speed, maximum | 0.3 m/s |
| Termination | Screw terminals |
| Cable section, minimum | 0.25 mmΒ² |
| Cable section, maximum | 2.5 mmΒ² |
| Length of sensor | 50 mm |
| Width of sensor | 87 mm |
| Height of sensor | 192 mm |
| Degree of protection | IP67 |
| Rated insulation voltage Ui | 400 V |
| Rated impulse withstand voltage Uimp | 2.5 kV |
| Thermal test current | 10 A |
| Rated control voltage | 24 VAC/DC |
| Required rated short-circuit current | - |
| Electrical power consumption, maximum | 10 W |
| Switching principle | slow action, positive break NC contact |
| Maximum switching frequency | 1,000 /h |
| Material of the contacts, electrical | Silver |
| Magnet switch-on time | 100 % |
| Test pulse duration, maximum | 5 ms |
| Test pulse interval, minimum | 50 ms |
| Voltage, Utilisation category AC-15 | 230 VAC |
| Voltage, Utilisation category DC-13 | 24 VDC |
| Length | - |
| Width | - |
| Switching element | - |
| Power to unlock | Yes |
| Cable entry | - |
Mail Us for your needs in SchmersalSolenoid interlocks TKF/9024VDC part no: 101010237 with budget-friendly prices. The Main Technical Parameters of TKF/9024VDC, 101010237 include electromechanical safety switch, designed for durability and reliability in industrial environments. The housing is made of Aluminium, ensuring a lightweight yet robust construction with a gross weight of 1,472 g. It features an Screw terminals system, facilitating easy installation. With dimensions of 50 mm in length, 87 mm in width, and 192 mm in height, it is compact yet highly efficient. The IP67 protection rating guarantees resistance against dust, water jets, and temporary immersion, making it suitable for demanding applications. The switch operates at a rated insulation voltage (Ui) of 400 V, ensuring electrical safety. Additionally, it has a rated impulse withstand voltage (Uimp) of 2.5 kV, providing high surge protection. Customize Your Experience with a Quote for your requirement of Solenoid interlocks. Experience the difference with our competitive pricing and superior support over other Suppliers.
