Schmersal TESZ102/30 Safety Switch
The Schmersal TESZ102/30 Safety Switch (Item No: 101029843) offers a Screw terminals M20 x 1.5 termination, IP65degree of protection, 250 VAC rated insulation voltage Ui, NO contact, NC contact switching element. Manufactured by Schmersal under the Schmersal Safety Switch. category, this model belongs to the Schmersal TE Series.
| Brand | Schmersal |
| Product Type | Safety Switch |
| Model Number | TESZ102/30 |
Schmersal TESZ102/30 Safety Switch – Technical Specifications
| Specification | Value |
|---|---|
| Material of the hinge | Aluminium |
| Gross weight | 460 g |
| Length x Width x Height | Suitable for mounting to profile systems: 30 mm |
| Standard | BG-GS-ET-15EN IEC 60947-5-1 |
| Housing material | Plastic, glass-fibre reinforced thermoplastic, self-extinguishing |
| Mounting hinge | Yes |
| Number of safety contacts | 1 |
| Standards | EN ISO 13849-1 |
| Mission time | 20 Year(s) |
| Mechanical life, minimum | 1,000,000 Operations |
| Positive break angle | 14 ° |
| Positive break force, minimum | 1 N |
| Termination | Screw terminals M20 x 1.5 |
| Cable section, minimum | 0.5 mm² |
| Cable section, maximum | 1.5 mm² |
| Length of sensor | 36 mm |
| Width of sensor | 111.5 mm |
| Height of sensor | 92 mm |
| Degree of protection | IP65 |
| Ambient temperature | -25 ... +65 °C |
| Rated insulation voltage Ui | 250 VAC |
| Rated impulse withstand voltage Uimp | 2.5 kV |
| Thermal test current | 2.5 A |
| Utilisation category AC-15 | 2 A |
| Switching element | NO contact, NC contact |
| Switching principle | Slow action |
| Maximum switching frequency | 120 /h |
| Material of the contacts, electrical | Silver |
| Number of auxiliary contacts | 1 |
Talk to Our Engineer for Schmersal Hinge safety switch TESZ102/30 Item No: 101029843 with exclusive offers. Core System Specifications of TESZ102/30, 101029843 are Screw terminals M20 x 1.5 cable entry, supporting cable sections from 0.5 mm² to 1.5 mm². The sensor has a length of 36 mm, width of 111.5 mm, and height of 92 mm, designed to fit seamlessly into industrial hinge systems. With an IP65 degree of protection, it resists dust and low-pressure water, making it ideal for harsh environments. It operates in ambient temperatures from -25 ... +65 °C. Electrical ratings include a rated insulation voltage (Ui) of 250 VAC and a rated impulse withstand voltage (Uimp) of 2.5 kV. The switch supports a thermal test current of 2.5 A and a utilization category of AC-15 at 2 A. It uses an NO contact, NC contact switching element with an Slow action switching principle. Don't Miss Out on a Quote for your requirement of Hinge safety switch TESZ102/30. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
