Schmersal TESK-LA-11L1-3M Safety Switch
The Schmersal TESK-LA-11L1-3M Safety Switch (Item No: 103005712) offers a cable termination, IP65degree of protection, 300 V rated insulation voltage Ui, NO contact, NC contact switching element. Manufactured by Schmersal under the Schmersal Safety Switch. category, this model belongs to the Schmersal TE Series.
| Brand | Schmersal |
| Product Type | Safety Switch |
| Model Number | TESK-LA-11L1-3M |
Schmersal TESK-LA-11L1-3M Safety Switch – Technical Specifications
| Specification | Value |
|---|---|
| Gross weight | 530 g |
| Housing material | Metal, zinc die-cast |
| Number of safety contacts | 1 |
| Standards | BG-GS-ET-15EN ISO 13849-1EN IEC 60947-5-1 |
| Mission time | 20 Year(s) |
| Mechanical life, minimum | 1,000,000 Operations |
| Termination | cable |
| Cable section, minimum | 0.5 mm² |
| Cable section, maximum | 1 mm² |
| Length of sensor | 20 mm |
| Width of sensor | 98 mm |
| Height of sensor | 116 mm |
| Degree of protection | IP65 |
| Ambient temperature | -25 ... +65 °C |
| Rated insulation voltage Ui | 300 V |
| Rated impulse withstand voltage Uimp | 2.5 kV |
| Thermal test current | 2.5 A |
| Utilisation category AC-15 | 2 A |
| Switching element | NO contact, NC contact |
| Switching principle | Slow action |
| Maximum switching frequency | 1,200 /h |
| Material of the contacts, electrical | Silver-nickel alloy 10 |
| Number of auxiliary contacts | 1 |
| Colour of the housing | Silver |
Get A Quote for Schmersal Hinge safety switch TESK-LA-11L1-3M Item No: 103005712 at the best price. Here are the brief Technical Specifications of TESK-LA-11L1-3M, 103005712 are cable cable entry, supporting cable sections from 0.5 mm² to 1 mm². The sensor has a length of 20 mm, width of 98 mm, and height of 116 mm, designed to fit seamlessly into industrial hinge systems. With an IP65 degree of protection, it resists dust and low-pressure water, making it ideal for harsh environments. It operates in ambient temperatures from -25 ... +65 °C. Electrical ratings include a rated insulation voltage (Ui) of 300 V and a rated impulse withstand voltage (Uimp) of 2.5 kV. The switch supports a thermal test current of 2.5 A and a utilization category of AC-15 at 2 A. It uses an NO contact, NC contact switching element with an Slow action switching principle. It's Time to get a Quote for your requirement of Hinge safety switch TESK-LA-11L1-3M. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
