Schmersal T. 441-11Y-14 Belt Alignment Switch
The Schmersal T. 441-11Y-14 Belt Alignment Switch (Item No: 101056537) offers a 10,000,000 Operations mechanical life, minimum, Screw terminals M20 x 1.5 termination, IP65 degree of protection, NO contact, NC contact switching element. Manufactured by Schmersal under the Schmersal Belt Alignment Switch. category, this model belongs to the Schmersal M Series.
| Brand | Schmersal |
| Product Type | Belt Alignment Switch |
| Model Number | T. 441-11Y-14 |
Schmersal T. 441-11Y-14 Belt Alignment Switch – Technical Specifications
| Specification | Value |
|---|---|
| Working principle | mechanical |
| Housing material | Grey cast iron, galvanised |
| Housing coating material | painted |
| Gross weight | 1,855 g |
| Number of normally closed (NC) | 1 |
| Number of normally open (NO) | 1 |
| B10DNormally-closed contact (NC) | 2,000,000 Operations |
| Mechanical life, minimum | 10,000,000 Operations |
| Contact opening | 2 x 6 mm |
| Termination | Screw terminals M20 x 1.5 |
| Cable section, minimum | 1.5 mm² |
| Cable section, maximum | 2.5 mm² |
| Length of sensor | 63 mm |
| Width of sensor | 106 mm |
| Height of sensor | 181 mm |
| Degree of protection | IP65 |
| Ambient temperature | -30 ... +90 °C |
| Rated insulation voltage Ui | 400 V |
| Rated impulse withstand voltage Uimp | 6 kV |
| Thermal test current | 16 A |
| Utilisation category AC-15 | 4 A |
| Switching element | NO contact, NC contact |
| Switching principle | Slow action |
| Maximum switching frequency | 3,000 /h |
| Material of the contacts, electrical | Silver |
Give Us a Call for Schmersal Belt Alignment Switch T. 441-11Y-14 Item No: 101056537 at the lowest pricing. In-depth Technical Analysis of T. 441-11Y-14, 101056537 feature mechanical power with a robust working principle, the unit is built using durable Grey cast iron, galvanised, painted housing for enhanced corrosion resistance. It features 2 x 6 mm contact openings and terminations via Screw terminals M20 x 1.5 cable entry. The minimum cable section supported is 1.5 mm², with a maximum of 2.5 mm², offering flexible wiring options. The sensor dimensions are compact 63 mm in length, 106 mm in width, and 181 mm in height—making it suitable for tight installation spaces. Rated for IP65 protection, it withstands harsh environments, including ambient temperatures from -30 ... +90 °C. With a rated insulation voltage Ui of 400 V and integrated NO contact, NC contact switching elements, this control panel ensures dependable signal processing. Elevate Your Project with a Quote for your requirement of Belt Alignment Switch T. 441-11Y-14. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
