Schmersal T. 422-01Y-M20 Belt Alignment Switch
The Schmersal T. 422-01Y-M20 Belt Alignment Switch (Item No: 101170462) offers a mechanical working principle, Screw terminals M20 x 1.5 termination, IP65 degree of protection, Opener (NC) switching element. Manufactured by Schmersal under the Schmersal Belt Alignment Switch. category, this model belongs to the Schmersal M Series.
| Brand | Schmersal |
| Product Type | Belt Alignment Switch |
| Model Number | T. 422-01Y-M20 |
Schmersal T. 422-01Y-M20 Belt Alignment Switch – Technical Specifications
| Specification | Value |
|---|---|
| Working principle | mechanical |
| Housing material | Grey cast iron, galvanised |
| Housing coating material | painted |
| Gross weight | 1,070 g |
| Number of normally closed (NC) | 1 |
| B10DNormally-closed contact (NC) | 2,000,000 Operations |
| Contact opening | 2 x 6 mm |
| Termination | Screw terminals M20 x 1.5 |
| Cable section, minimum | 1.5 mm² |
| Cable section, maximum | 2.5 mm² |
| Length of sensor | 63 mm |
| Width of sensor | 106 mm |
| Height of sensor | 97 mm |
| Degree of protection | IP65 |
| Ambient temperature | -30 ... +90 °C |
| Thermal test current | 16 A |
| Utilisation category AC-15 | 4 A |
| Switching element | Opener (NC) |
| Material of the contacts, electrical | Silver |
Mail Us for your needs in Schmersal Belt Alignment Switch T. 422-01Y-M20 Item No: 101170462 with budget-friendly prices. The Main Technical Parameters of T. 422-01Y-M20, 101170462 include mechanical power with a robust working principle, the unit is built using durable Grey cast iron, galvanised, painted housing for enhanced corrosion resistance. It features 2 x 6 mm contact openings and terminations via Screw terminals M20 x 1.5 cable entry. The minimum cable section supported is 1.5 mm², with a maximum of 2.5 mm², offering flexible wiring options. The sensor dimensions are compact 63 mm in length, 106 mm in width, and 97 mm in height—making it suitable for tight installation spaces. Rated for IP65 protection, it withstands harsh environments, including ambient temperatures from -30 ... +90 °C. With integrated Opener (NC) switching elements, this control panel ensures dependable signal processing. Customize Your Experience with a Quote for your requirement of Belt Alignment Switch T. 422-01Y-M20. Experience the difference with our competitive pricing and superior support over other Suppliers.
