Schmersal SLG 420-E/R0800-03-RFH Safety Light Grids
The Schmersal SLG 420-E/R0800-03-RFH Safety Light Grids (Item No: 101207363) offers a 10 ms reaction time, maximum, Connector plug M12, 8-pole terminal connector, Recipient, Connector plug M12, 4-pole terminal, Connector, Transmitter, IP67 degree of protection. Manufactured by Schmersal under the Schmersal Safety Light Grids. category, this model belongs to the Schmersal SLG Series.
| Brand | Schmersal |
| Product Type | Safety Light Grids |
| Model Number | SLG 420-E/R0800-03-RFH |
Schmersal SLG 420-E/R0800-03-RFH Safety Light Grids β Technical Specifications
| Specification | Value |
|---|---|
| Housing material | Aluminium |
| Reaction time, maximum | 10 ms |
| PFH value | 6.19 x 10β»βΉ /h |
| Detection ability for test bodies at v = 1.6 m/s | 400 mm |
| Height of the protection field | 800 mm |
| Range, protection field, minimum | 8 m |
| Range, protection field, maximum | 50 m |
| Wave length of the laserdiode | 880 nm |
| Length of cable | 100 m |
| Termination | Connector |
| Terminal connector, Recipient | Connector plug M12, 8-pole |
| Terminal, Connector, Transmitter | Connector plug M12, 4-pole |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +50 Β°C |
| Storage and transport temperature | -25 ... +70 Β°C |
| Protection class | III |
| Switching voltage OSSD, HIGH signal | 24 V |
| Electrical power consumption of the receiver, maximum | 8 W |
| Electrical power consumption of the transmitter, maximum | 4 W |
| Output current, (fail-safe output), maximum | 0.5 A |
| Design of control elements | p-type |
| Gross weight | 3,780 g |
Talk to Our Engineer for Schmersal 4-Pole Connector Plug Light Grids SLG 420-E/R0800-03-RFH part no: 101207363 at unbeatable prices. The Main Technical Parameters of SLG 420-E/R0800-03-RFH, 101207363 are Aluminium Housing, ensuring durability and long-lasting performance. With a maximum Reaction time of just 10 ms it provides quick and efficient safety responses. The Length of the cable is 100 m offering flexibility in installation. Termination is achieved via Connector plugs, with the Recipient side using an Connector plug M12, 8-pole and the Transmitter side equipped with an Connector plug M12, 4-pole. The Diameter of sensor , Degree of protection IP67 and Ambient temperature -25 ... +50 Β°C. Capture the Best Deal with a Quote for your requirement of . Our promise: More affordable pricing and more personalized support than other Dealers.
