Schmersal RWS32 Spring-return Selector Switch
The Schmersal RWS32 Spring-return Selector Switch (Item No: 101188353) offers a 3 number of switch positions, 300,000 Operations mechanical life, minimum, 22.3 mm mounting diameter, IP65 degree of protection. Manufactured by Schmersal under the Schmersal Spring-return Selector Switch. category, this model belongs to the Schmersal RW Series.
| Brand | Schmersal |
| Product Type | Spring-return Selector Switch |
| Model Number | RWS32 |
Schmersal RWS32 Spring-return Selector Switch – Technical Specifications
| Specification | Value |
|---|---|
| Versions | Step selector switch |
| Installation conditions (mechanical) | arbitrarily |
| Toggle | short |
| Sealing type | MembraneLip gasketsForm seals |
| Material of the operators | ABS |
| Material of the front ring | Aluminium |
| Colour of the front ring | Silver |
| Colour of the handle | Grey |
| Gross weight | 50 g |
| Latching | Yes |
| Fully insulated | Yes |
| Number of plunger | 2 |
| Number of switch positions | 3 |
| Unlocking | Rotating unlatcher |
| Latching position | leftright |
| Mechanical life, minimum | 300,000 Operations |
| Switching angle, left | 55 ° |
| Switching angle, right | 55 ° |
| Mounting | Mounting flange EFM |
| Tightening torque of the screw | 0.6 Nm |
| Diameter total | 39.5 mm |
| Diameter of the front ring | 39.5 mm |
| Length of the handle | 25 mm |
| Diameter of the knob | 30 mm |
| Mounting diameter | 22.3 mm |
| Thickness, of the front panel, minimum | 1 mm |
| Thickness of the front panel, maximum | 6 mm |
| Spacing | 50 x 60 mm |
| Degree of protection | IP65 |
| Restistance to shock | 30 g / 18 ms |
| Resistant to vibration | 20 g / 10 ... 150 Hz |
