RSS 36-I2-D-ST5: 103025098 - Schmersal 106.3 mm Width of Safety Sensors
Technical Specifications Schmersal 106.3 mm Width of Safety Sensors RSS 36-I2-D-ST5 103025098:
| Working Principle | RFID |
| PFH value | 2.70 x 10โปยนโฐ /h |
| Termination | Connector M12, 5-pole, A-coded |
| Operating Voltage | 24 VDC -15 % / +10 % (stabilised PELV power supply) |
Schmersal 106.3 mm Width of Safety Sensors, RSS 36-I2-D-ST5, 103025098 Technical Specifications:
| Specification | Value |
|---|---|
| Working principle | RFID |
| Frequency band RFID | 125 kHz |
| Transmitter output RFID, maximum | -6 dB/m |
| Housing construction form | Block |
| Installation conditions (mechanical) | Not flush |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Reaction time, maximum | 100 ms |
| Duration of risk, maximum | 200 ms |
| Reaction time, switching off safety outputs via actuator, maximum | 100 ms |
| Reaction time, switching off safety outputs via safety inputs, maximum | 0.5 ms |
| Number of LEDs | 3 |
| Number of semi-conductor outputs with signaling function | 1 |
| Number of fail-safe digital outputs | 2 |
| Performance Level, up to | e |
| Category | 4 |
| PFH value | 2.70 x 10โปยนโฐ /h |
| PFD value | 2.10 x 10โปโต |
| Actuating panels | lateral |
| Active area | lateral |
| Mounting | A screw length of 25 mm is sufficient for sensor mounting and for side mounting of the actuators. 30 mm long screws are recommended when the actuator is mounted upright and/or when the sealing discs are used. |
| Type of the fixing screws | 2x M4 (cylinder head screws with washers DIN 125A / form A) |
| Tightening torque of the fixing screws, minimum | 2.2 Nm |
| Tightening torque of the fixing screws, maximum | 2.5 Nm |
| Switch distance, typical | 12 mm |
| Hysteresis (Switching distance), maximum | 2 mm |
| Repeat accuracy R | 0.5 mm |
| Termination | Connector M12, 5-pole, A-coded |
| Length of sensor | 22 mm |
| Width of sensor | 106.3 mm |
IndMALL provides 106.3 mm Width of Safety Sensors RSS 36-I2-D-ST5 part no: 103025098 at the lowest pricing. In-depth Technical Analysis of RSS 36-I2-D-ST5, 103025098 include RFID Magnetic Reed Switch Sensor designed for industrial applications requiring precise control and reliability. Operating within a 125 kHz frequency band, this sensor features a Block housing constructed from Glass-fibre, reinforced thermoplastic ensuring durability and resilience. The sensor has a maximum reaction time of 100 ms and a typical switch distance of 12 mm with a hysteresis of 2 mm for accurate switching operations. It uses an Connector M12, 5-pole, A-coded for secure termination. The sensor measures 22 mm in length and operates at 24 VDC -15 % / +10 % (stabilised PELV power supply) accommodating a current of 600 mA. The sensor is rated IP65, IP67, IP69. Capture the Best Deal with a Quote for your requirement of 106.3 mm Width of Safety Sensors. Our promise: More affordable pricing and more personalized support than other Dealers.
