Schmersal RSS 36-I1-D-R Command and Signalling Devices
The Schmersal RSS 36-I1-D-R Command and Signalling Devices offers a 1,000,000 Operations mechanical life, minimum, Cable (Y UL 2517), 8 poletermination, IP65IP67IP69 degree of protection, 32 VDC rated insulation voltage Ui. Manufactured by Schmersal under the Schmersal Command and Signalling Devices. category, this model belongs to the Schmersal WK Series.
| Brand | Schmersal |
| Product Type | Command and Signalling Devices |
| Model Number | RSS 36-I1-D-R |
Schmersal RSS 36-I1-D-R Command and Signalling Devices β Technical Specifications
| Specification | Value |
|---|---|
| Installation conditions (mechanical) | not flush |
| Gross weight | 80 g |
| Mechanical life, minimum | 1,000,000 Operations |
| Mounting | A screw length of 25 mm is sufficient for sensor mounting and for side mounting of the actuators. 30 mm long screws are recommended when the actuator is mounted upright and/or when the sealing discs are used. |
| Termination | Cable (Y UL 2517), 8 pole |
| Cable section, maximum | 8 x 0.35 mmΓΒ² |
| Degree of protection | IP65IP67IP69 |
| Ambient temperature | 28 ... +70 ΓΒ°C |
| Resistance to vibrations | 10 Γ’β¬Β¦ 55 Hz, amplitude 1 mm |
| Restistance to shock | 30 g / 11 ms |
| Rated insulation voltage Ui | 32 VDC |
| Rated impulse withstand voltage Uimp | 0.8 kV |
| Degree of pollution | 3 |
