Schmersal PSC1-C-100-FB1 Safety controllers
The Schmersal PSC1-C-100-FB1 Safety controllers (Item No: 103008452) offers a 1.22 x 10β»βΈ /h PFH value, Removable screw terminals, IP20 degree of protection, 24 VDC rated operating voltage. Manufactured by Schmersal under the Schmersal Safety controllers. category, this model belongs to the Schmersal PSC Series.
| Brand | Schmersal |
| Product Type | Safety controller |
| Model Number | PSC1-C-100-FB1 |
Schmersal PSC1-C-100-FB1 Safety controllers β Technical Specifications
| Specification | Value |
|---|---|
| PFH value | 1.22 x 10β»βΈ /h |
| Mounting | can be clipped into standard rail |
| Cable section, minimum | 0.2 mmΒ² |
| Cable section, maximum | 2.5 mmΒ² |
| Wire cross-section, minimum | 24 AWG |
| Wire cross-section, maximum | 12 AWG |
| Wire cross-section | 24 ... 12 AWG |
| Terminal (mechanical) | Removable screw terminals |
| Width | 112.5 mm |
| Height | 100 mm |
| Depth | 115 mm |
| Degree of protection | IP20 |
| Ambient temperature | 0 ... +50 Β°C |
| Storage and transport temperature | -25 ... +70 Β°C |
| Relative humidity, minimum | 5 % |
| Relative humidity, maximum | 85 % |
| Permissible installation altitude above sea level, maximum | 2,000 m |
| Operating voltage | 24 VDC -15 % / +20 % |
| Rated operating voltage | 24 VDC |
| Designation, Communication interface | RJ45 |
| Rated operating current (safety outputs) | 2,000 mA |
| Design of control elements | short-circuit proof, p-type (Q2 und Q3) |
| Gross weight | 986 g |
Request a Quote for Schmersal 6 Signalling Output Safety Controller PSC1-C-100-FB1 (Part No: 103008452) at the most competitive price with IndMALL Automation. Engineered for high-performance safety applications, this controller boasts a PFH value of 1.22 x 10β»βΈ /h, ensuring exceptional reliability and compliance with safety regulations. Designed for hassle-free installation, it easily clips onto standard rails, while the removable screw terminals provide secure and stable connections for optimal functionality.
Operating at 24 VDC with a rated current of 2,000 mA, it is ideal for industrial automation and safety applications. Its compact build, measuring 100 mm in height and 115 mm in depth, allows for effortless integration into confined spaces. With an IP20 protection rating, it offers resistance against solid particles, while its weight of 986 g ensures durability and robustness.
Get your quote today and take advantage of best-in-class pricing and expert support, surpassing other dealers and distributors in the industry.
