Schmersal MJ 064-03Y Limit Switch
The Schmersal MJ 064-03Y Limit Switch (Item No: 101056945) offers a mechanical working principle, 30,000 Operationsmechanical life, minimum, Screw terminals M20 x 1.5 termination, IP65 degree of protection. Manufactured by Schmersal under the Schmersal Limit Switch. category, this model belongs to the Schmersal TV Series.
| Brand | Schmersal |
| Product Type | Limit Switch |
| Model Number | MJ 064-03Y |
Schmersal MJ 064-03Y Limit Switch β Technical Specifications
| Specification | Value |
|---|---|
| Working principle | mechanical |
| Slide form | Castor |
| Housing material | Grey cast iron, galvanised |
| Housing coating material | painted |
| Gross weight | 3,880 g |
| Number of normally closed (NC) | 3 |
| Number of normally open (NO) | - |
| Actuating element | Offset roller lever |
| Roller material | Plastic |
| Mechanical life, minimum | 30,000 Operations |
| Actuating angle, from left of switch axis | 30 Β° |
| Actuating angle, from right of switch axis | 45 Β° |
| Contact opening | 2 x 4 mm |
| Actuating speed, minimum | 600 mm/min |
| Actuating speed, maximum | 1 m/s |
| Termination | Screw terminals M20 x 1.5 |
| Cable section, maximum | 4 mmΒ² |
| Connection technique - Wire cross-section | 11 AWG |
| Length of sensor | 149 mm |
| Width of sensor | - |
| Height of sensor | 90 mm |
| Width of Castor | 9 mm |
| Diameter of Castor | 36 mm |
| Degree of protection | IP65 |
| Ambient temperature | -30 ... +90 Β°C |
| Rated insulation voltage Ui | 500 V |
| Thermal test current | 25 A |
| Utilisation category AC-15 | 25 A |
| Switching element | Opener (NC) |
| Switching principle | Snap action |
| Material of the contacts, electrical | Silver |
Call us for Medium-duty position switches MJ 064-03Y part no: 101056945 at the best rates. Technical Attributes of MJ 064-03Y, 101056945 are Grey cast iron, galvanised, ensuring durability in industrial environments. The switch features a Offset roller lever actuating element, providing precise mechanical operation. With a gross weight of 3,880 g, it maintains a compact yet robust design. The connection technique supports 11 AWG wire cross-section, ensuring reliable electrical connections. Dimensions include a sensor length of 149 mm, Switching element Opener (NC), and height of 90 mm. The castor width is 9 mm, with a diameter of 36 mm, enhancing mechanical efficiency. The unit is rated IP65, offering protection against dust and water ingress. Designed for high-voltage applications, it features a rated insulation voltage (Ui) of 500 V, ensuring electrical safety. Unlock Exclusive Pricing with a Quote for your requirement of Medium-duty position switches . Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
