Schmersal KA-0804 Connector
The Schmersal KA-0804 Connector (Item No: 101207741) offers a 5 m length of cable, PVC material of the cable mantle, IP67 degree of protection, 250 VAC rated operating voltage. Manufactured by Schmersal under the Schmersal Connector. category, this model belongs to the Schmersal KA Series.
| Brand | Schmersal |
| Product Type | Connector |
| Model Number | KA-0804 |
Schmersal KA-0804 Connector – Technical Specifications
| Specification | Value |
|---|---|
| Product type description | KA-0804 |
| Gross weight | 200 g |
| Number of cable wires | 4 |
| Length of cable | 5 m |
| Material of the Cable mantle | PVC |
| Pin assignment - PIN 1 | Brown |
| Pin assignment - PIN 2 | White |
| Pin assignment - PIN 3 | Blue |
| Pin assignment - PIN 4 | Black |
| Number of poles | 4 |
| Wire cross-section | 0.34 mm2 |
| Degree of protection | IP67 |
| Ambient temperature (Connector) | -30 ... +90 °C |
| Rated operating voltage | 250 VAC |
