Schmersal IFL 4-120L-01P Photo-electric Proximity Switches
The Schmersal IFL 4-120L-01P Photoelectric Proximity Switches (Item No: 101117699) offers a Cylinder, thread housing construction form, 71 mmlength of sensor, 10 ... 30 VDC rated operating voltage, IP67 degree of protection. Manufactured by Schmersal under the Schmersal Photoelectric Proximity Switches. category, this model belongs to the Schmersal IF Series.
| Brand | Schmersal |
| Product Type | Photo-electric Proximity Switch |
| Model Number | IFL 4-120L-01P |
Schmersal IFL 4-120L-01P Photo-electric Proximity Switches – Technical Specifications
| Specification | Value |
|---|---|
| Housing construction form | Cylinder, thread |
| Housing material | Plastic |
| Active area | Plastic |
| Material of the nuts | Plastic |
| Material of the washer | Perbunan® |
| Gross weight | 88 g |
| Integral system diagnostics, status | Yes |
| Number of cable wires | 3 |
| Tightening torque of nuts, maximum | 0.9 Nm |
| Wire cross-section | 0.34 mm2 |
| ISO thread of the sensor | M12 |
| Length of sensor | 71 mm |
| Width of sensor | 10.6 mm |
| Height of sensor | 10.6 mm |
| Degree of protection | IP67 |
| Protection class | II |
| Type of voltage range | DC |
| Rated operating voltage | 10 ... 30 VDC |
| Operating current | 200 mA |
| Protection circuit integrated | inductive interference protectionProtection against polarity reversalSurge protectionMax. fuse rating |
| Switching frequency, approx. | 700 Hz |
| Design of control elements | p-type |
| Note (Integral System Diagnostics, status ) | yellow LED |
Ask for the Pricing of Schmersal Inductive Proximity Switches IFL 4-120L-01P part no: 101117699 at unbeatable prices. Detailed Specifications of IFL 4-120L-01P, 101117699 feature Cylinder, thread Plastic housing, ensuring lightweight durability for industrial applications. Designed for versatile electrical compatibility, it operates at a rated voltage of 10 ... 30 VDC with a maximum operating current of 200 mA. The switching element supports both , allowing flexible configurations. With an approximate switching frequency of 700 Hz, it ensures reliable performance in automation setups. The maximum voltage drop (Ud) is , with a current rating of at Ud, providing efficient electrical conductivity. The control element features an p-type design, ensuring simplified wiring for seamless integration. Termination is achieved via a , ensuring secure and stable electrical contacts. The unit is IP67 rated, offering protection against dust and low-pressure water jets. Now's the Time to Secure a Quote for your requirement of Inductive Proximity Switches. We're committed to offering more favorable pricing and more responsive support than other Traders.
