Schmersal IFL 10-30L-10TN Photo-electric Proximity Switches
The Schmersal IFL 10-30L-10TN Photoelectric Proximity Switches (Item No: 101126988) offers a Cylinder, thread housing construction form, Cabletermination, 10 ... 30 VDC rated operating voltage, Normally open contact (NO) switching element. Manufactured by Schmersal under the Schmersal Photoelectric Proximity Switches. category, this model belongs to the Schmersal IF Series.
| Brand | Schmersal |
| Product Type | Photo-electric Proximity Switch |
| Model Number | IFL 10-30L-10TN |
Schmersal IFL 10-30L-10TN Photo-electric Proximity Switches β Technical Specifications
| Specification | Value |
|---|---|
| Housing construction form | Cylinder, thread |
| Housing material | Brass |
| Active area | Plastic |
| Material of the nuts | Brass |
| Gross weight | 198 g |
| Integral system diagnostics, status | Yes |
| Number of cable wires | 3 |
| Tightening torque of nuts, maximum | 30 Nm |
| Termination | Cable |
| Wire cross-section | 0.34 mm2 |
| ISO thread of the sensor | M30 |
| width across flats | 36 BK |
| Length of sensor | 100 mm |
| Degree of protection | IP67 |
| Type of voltage range | DC |
| Rated operating voltage | 10 ... 30 VDC |
| Operating current | 200 mA |
| Switching element | Normally open contact (NO) |
| Protection circuit integrated | inductive interference protectionProtection against polarity reversalSurge protectionMax. fuse rating |
| Switching frequency, approx. | 350 Hz |
| Voltage drop Ud, maximum | 1.2 V |
| Current at Voltage drop Ud | 0.2 A |
| Design of control elements | n-type |
| Note (Integral System Diagnostics, status ) | yellow LED |
Mail Us for your needs in Schmersal Inductive Proximity Switches IFL 10-30L-10TN part no: 101126988 with budget-friendly prices. The Main Technical Parameters of IFL 10-30L-10TN, 101126988 include Cylinder, thread Brass housing, ensuring lightweight durability for industrial applications. Designed for versatile electrical compatibility, it operates at a rated voltage of 10 ... 30 VDC with a maximum operating current of 200 mA. The switching element supports both Normally open contact (NO), allowing flexible configurations. With an approximate switching frequency of 350 Hz, it ensures reliable performance in automation setups. The maximum voltage drop (Ud) is 1.2 V, with a current rating of 0.2 A at Ud, providing efficient electrical conductivity. The control element features an n-type design, ensuring simplified wiring for seamless integration. Termination is achieved via a Cable, ensuring secure and stable electrical contacts. The unit is IP67 rated, offering protection against dust and low-pressure water jets. Customize Your Experience with a Quote for your requirement of Inductive Proximity Switches. Experience the difference with our competitive pricing and superior support over other Suppliers.
