Schmersal HDTP30-BL-GN Command and Signalling Devices
The Schmersal HDTP30-BL-GN Command and Signalling Devices offers a 22.3 mm mounting diameter, 6 mmthickness of the front panel, maximum, IP67IP69K degree of protection, 48 mm mounting depth. Manufactured by Schmersal under the Schmersal Command and Signalling Devices. category, this model belongs to the Schmersal WK Series.
| Brand | Schmersal |
| Product Type | Command and Signalling Devices |
| Model Number | HDTP30-BL-GN |
Schmersal HDTP30-BL-GN Command and Signalling Devices β Technical Specifications
| Specification | Value |
|---|---|
| Material of the front ring | stainless steel |
| Material of the bellows | Silicone |
| Colour of the front ring | Silver |
| Colour of the bellows | Blue |
| Gross weight | 51 g |
| Probing possible | Yes |
| Number of switch positions | 1 |
| Mounting | central nut |
| Mounting depth | 48 mm |
| Mounting diameter | 22.3 mm |
| Thickness, of the front panel, minimum | 1.5 mm |
| Thickness of the front panel, maximum | 6 mm |
| Spacing | 65 x 65 mm |
| Degree of protection | IP67IP69K |
| Ambient temperature | 25 ... +80 ΓΒ°C |
