Schmersal EX-BNS 33-12ZG-2187-3GD 5M Safety Sensor
The Schmersal EX-BNS 33-12ZG-2187-3GD 5M Safety Sensor (Item No: 103050114) offers a 5 m length of cable, Cable termination, IP67 degree of protection, 25 mm height of sensor. Manufactured by Schmersal under the Schmersal Safety Sensor. category, this model belongs to the Schmersal BNS Series.
| Brand | Schmersal |
| Product Type | Safety Sensor |
| Model Number | EX-BNS 33-12ZG-2187-3GD 5M |
Schmersal EX-BNS 33-12ZG-2187-3GD 5M Safety Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Gross weight | 290 g |
| Installation conditions (mechanical) | not flush |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Coding | Yes |
| Integral system diagnostics, status | Yes |
| Mission time | 20 Year(s) |
| Actuating element | Magnet |
| Direction of motion | Head-on to the active surface |
| Assured switching distance "ON" Sao | 5 mm |
| Assured switching distance "OFF" Sar | 15 mm |
| Length of cable | 5 m |
| Termination | Cable |
| Wire cross-section | 23 AWG |
| Material of the Cable mantle | PVC |
| Length of sensor | 13 mm |
| Height of sensor | 25 mm |
| Degree of protection | IP67 |
| Resistance to vibrations | 10 … 55 Hz, amplitude 1 mm |
| Restistance to shock | 30 g / 11 ms |
