Schmersal EDPSW Door Handle System
The Schmersal EDPSW Door Handle System (Item No: ) offers a Mounting flange EFM mounting, IP65 degree of protection, 22.3 mm mounting diameter, 1 mm thickness, of the front panel, minimum. Manufactured by Schmersal under the Schmersal Door Handle System. category, this model belongs to the Schmersal UHS Series.
| Brand | Schmersal |
| Product Type | Door handle system |
| Model Number | EDPSW |
Schmersal EDPSW Door Handle System β Technical Specifications
| Specification | Value |
|---|---|
| Gross weight | 48 g |
| Actuating stroke | 5 mm |
| Tightening torque of the screw | 0.6 Nm |
| Height | 27.5 mm |
| Degree of protection | IP65 |
| Restistance to shock | 30 g / 18 ms |
| Maximum switching frequency | 1,200 /h |
| Versions | Latched pushbutton Front plate mounting |
| Design | Round |
| Sealing type | Form seals |
| Material of the operators | Aluminium |
| Material of the front ring | Aluminium |
| Colour of the operating element | Black |
| Colour of the front ring | Silver |
| Unlocking | without |
| Actuating force, approx. | 2 N |
| Mounting | Mounting flange EFM |
| Diameter total | 32 mm |
| Mounting diameter | 22.3 mm |
| Thickness, of the front panel, minimum | 1 mm |
| Thickness of the front panel, maximum | 6 mm |
| Spacing | 50 x 60 mm |
| Ambient temperature | 25 ... +75 ΓΒ°C |
| Resistant to vibration | 20 g / 10 ... 150 Hz |
Send Your Inquiry for Schmersal Door Handle System EDPSW Item No: 101006290 with cost-effective solutions. Essential Technical Specs of EDPSW, 101006290 are designed in a Round form, this system ensures comfortable and reliable operation. The operating elements are made of high-quality Aluminium, finished in a clean Black color for visibility and aesthetics. The DHS system uses a Mounting flange EFM for secure mounting, suitable for applications where stability and quick installation are essential. It fits perfectly into panels with a mounting diameter of 22.3 mm and supports front panel thicknesses ranging from 1 mm to 6 mm. Engineered for demanding environments, it operates reliably in ambient temperatures from 25 ... +75 ΓΒ°C. Whether for machinery or control panels, the DHS system adds both functionality and safety. Capture the Best Deal with a Quote for your requirement of Door Handle System EDPSW. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
