BNS-B20-12ZG-H-5M: 101187773 - Schmersal Schmersal PVC Cable Mantle Safety Sensors
Technical Specifications of Schmersal PVC Cable Mantle Safety Sensors BNS-B20-12ZG-H-5M 101187773:
| Working principle | Magnetic drive |
| Assured switching distance "ON" Sao | 0 mm |
| Assured switching distance "OFF" Sar | 22 mm |
| Termination | Pre-wired cable |
Schmersal Schmersal PVC Cable Mantle Safety Sensors, BNS-B20-12ZG-H-5M, 101187773 Technical Specifications:
| Specification | Value |
|---|---|
| Working principle | Magnetic drive |
| Installation conditions (mechanical) | quasi-flush |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Number of normally closed (NC) | 2 |
| Number of normally open (NO) | 1 |
| Number of safety contacts | 2 |
| Number of cable wires | 6 |
| Actuating element | Magnet |
| Latching force | 100 N |
| Door weight, Sliding guard, maximal | 3 kg |
| Door weight, Hinged guard, maximal | 5 kg |
| Assured switching distance "ON" Sao | 0 mm |
| Assured switching distance "OFF" Sar | 22 mm |
| Length of cable | 5 m |
| Termination | Pre-wired cable |
| Wire cross-section | 0.25 mm2 |
| Material of the Cable mantle | PVC |
| Length of sensor | 43.3 mm |
| Width of sensor | 119.5 mm |
| Height of sensor | 140 mm |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +70 Β°C |
| Storage and transport temperature | -25 ... +70 Β°C |
| Resistance to vibrations | 10 β¦ 55 Hz, amplitude 1 mm |
| Restistance to shock | 30 g / 11 ms |
| Switching voltage, maximum | 24 VDC |
| Switching current, maximum | 0.01 A |
| Switching capacity, maximum | 0.24 W |
| Switching frequency, maximum | 5 Hz |
| Gross weight | 340 g |
Obtain a Quote for Schmersal PVC Cable Mantle Safety Sensors BNS-B20-12ZG-H-5M part no: 101187773 at economical prices. Specifications Overview for BNS-B20-12ZG-H-5M, 101187773 revealsMagnetic drive principle, housed in durable Glass-fibre, reinforced thermoplastic material, ensuring longevity and resilience. It utilizes a Magnet as the actuating element with a strong latching force of 100 N, providing secure and reliable operation. The sensor features an assured switching distance 0 mm and 22 mm with a 5 m cable for easy installation. The and Pre-wired cable entry and secure termination ensure stable connectivity. It supports a maximum switching voltage of 24 VDC and a switching current of 0.01 A with a switching frequency of up to 5 Hz. Rated IP67 this sensor is well-protected against dust and water ingress, making it suitable for harsh environments. With a gross weight of just 340 g. Take the First Step with a Quote for your requirement of Schmersal PVC Cable Mantle Safety Sensors. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
