BNS 36-11Z-ST-R: 101193154 - Schmersal Side Sensing Safety Sensors
Technical Specifications of Schmersal Side Sensing Safety Sensors BNS 36-11Z-ST-R 101193154:
| Working principle | Magnetic drive |
| Termination | Connector M8, 4-pole, Latching interlocking |
| Degree of protection | IP67 |
Schmersal Side Sensing Safety Sensors, BNS 36-11Z-ST-R, 101193154 Technical Specifications:
| Specification | Value |
|---|---|
| Working principle | Magnetic drive |
| Installation conditions (mechanical) | quasi-flush |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Number of normally closed (NC) | 1 |
| Number of safety contacts | 2 |
| Actuating element | Magnet |
| Door hinge | Right |
| Direction of motion | Head-on to the active surface |
| Termination | Connector M8, 4-pole, Latching interlocking |
| Length of sensor | 13 mm |
| Width of sensor | 88 mm |
| Height of sensor | 25 mm |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +70 Β°C |
| Storage and transport temperature | -25 ... +70 Β°C |
| Resistance to vibrations | 10 β¦ 55 Hz, amplitude 1 mm |
| Restistance to shock | 30 g / 11 ms |
| Switching voltage, maximum | 75 VDC |
| Switching current, maximum | 0.4 A |
| Switching capacity, maximum | 10 W |
| Switching element | 1 NO contact, 1 NC contacts |
| Switching frequency, maximum | 5 Hz |
| Gross weight | 29 g |
Get A Quote for Schmersal Side Sensing Safety Sensors BNS 36-11Z-ST-R part no: 101193154 at the best price. Here are the brief Technical Specifications of BNS 36-11Z-ST-R, 101193154 are Magnetic drive Working principle. The sensor is housed in a durable Glass-fibre, reinforced thermoplastic material, ensuring long-lasting performance even in demanding environments. It features a reliable Magnet as the actuating element, making it ideal for various safety applications. The sensor comes with a and Connector M8, 4-pole, Latching interlocking for easy installation and connectivity. The termination is secure, ensuring stable performance over time. With a maximum switching voltage of 75 VDC and a current capacity of 0.4 A the sensor supports a switching frequency of up to 5 Hz making it highly efficient for safety-critical operations. Rated with an IP67 degree of protection. It's Time to get a Quote for your requirement of Schmersal Side Sensing Safety Sensors. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
