BNS 260-02/01Z-ST-L: 101184378 - Schmersal Safety Sensors with Fail-Safe Design
Technical Specifications of Safety Sensors with Fail-Safe Design BNS 260-02/01Z-ST-L 101184378:
| Working principle | Magnetic drive |
| Termination | Connector 8 mm, 6-pole, Latching interlocking |
| Degree of Protection | IP67 |
Schmersal Safety Sensors with Fail-Safe Design, BNS 260-02/01Z-ST-L, 101184378 Technical Specifications:
| Specification | Value |
|---|---|
| Working principle | Magnetic drive |
| Installation conditions (mechanical) | Quasi Flush |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Number of normally closed (NC) | 3 |
| Number of safety contacts | 2 |
| Actuating element | Magnet |
| Door hinge | Left |
| Direction of motion | Head-on to the active surface |
| Assured switching distance "ON" Sao | 5 mm |
| Assured switching distance "OFF" Sar | 15 mm |
| Termination | Connector 8 mm, 6-pole, Latching interlocking |
| Length of sensor | 13 mm |
| Width of sensor | 26 mm |
| Height of sensor | 36 mm |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +70 Β°C |
| Storage and transport temperature | -25 ... +70 Β°C |
| Resistance to vibrations | 10 β¦ 55 Hz, amplitude 1 mm |
| Restistance to shock | 30 g / 11 ms |
| Rated insulation voltage Ui | 50 VAC |
| Rated impulse withstand voltage Uimp | 0.8 kV |
| Required rated short-circuit current | 100 A |
| Switching voltage, maximum | 30 VDC |
| Switching current, maximum | 0.4 A |
| Switching capacity, maximum | 10 VA |
| Switching element | 3 NC contact |
| Switching frequency, maximum | 5 Hz |
| Gross weight | 31 g |
Talk to Our Engineer for Safety Sensors with Fail-Safe Design BNS 260-02/01Z-ST-L at Exclusive Prices
Reach out for a quote on Safety Sensors with Fail-Safe Design BNS 260-02/01Z-ST-L (Part No: 101184378) with exclusive offers.
Core System Specifications:
Principle: Magnetic drive
Housing: Sturdy Glass-fibre, reinforced thermoplastic, ensuring durability and long-term reliability
Actuating Element: Magnet optimized for smooth operation, with 5 mm and 15 mm switching distances for accurate performance
Cable & Termination: Features a 1 m cable and 8 mm, 6-pole Latching interlocking connector for easy installation and secure connection
Voltage & Current: Maximum switching voltage of 30 VDC and 0.4 A, with a switching frequency of up to 5 Hz
Protection Rating: Rated IP67, offering top-tier dust and water resistance
