BNS 250-11Z 2,5M: 101125869 - Schmersal Schmersal Magnetic Drive Safety Switch
Technical Specifications of Schmersal Magnetic Drive Safety Switch BNS 250-11Z 2,5M 101125869:
| Working principle | Magnetic drive |
| Length of cable | 5 m |
| Termination | Cable |
| Degree of protection | IP67 |
Schmersal Schmersal Magnetic Drive Safety Switch, BNS 250-11Z 2,5M, 101125869 Technical Specifications:
| Specification | Value |
|---|---|
| Working principle | Magnetic drive |
| Installation conditions (mechanical) | not flush |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Number of normally closed (NC) | 2 |
| Actuating element | Magnet |
| Direction of motion | Head-on to the active surface |
| Assured switching distance "ON" Sao | 5 mm, 8 mm |
| Assured switching distance "OFF" Sar | 15 mm, 18 mm |
| Length of cable | 5 m |
| Termination | Cable |
| Wire cross-section | 23 AWG |
| Material of the Cable mantle | PVC |
| Length of sensor | 13 mm |
| Width of sensor | 88 mm |
| Height of sensor | 25 mm |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +70 Β°C |
| Storage and transport temperature | -25 ... +70 Β°C |
| Resistance to vibrations | 10 β¦ 55 Hz, amplitude 1 mm |
| Restistance to shock | 30 g / 11 ms |
| Switching current, maximum | 0.01 A |
| Switching capacity, maximum | 3 W |
| Switching element | 2 NC contact |
| Switching frequency, maximum | 5 Hz |
| Design of control elements | Miscellaneous, Reed contacts |
| Gross weight | 195 g |
Call us for Schmersal Magnetic Drive Safety Switch BNS 250-11Z 2,5M part no: 101125869 at the best rates. Technical Attributes of BNS 250-11Z 2,5M, 101125869 are Glass-fibre, reinforced thermoplastic ensuring durability and reliability in demanding environments. The sensor operates on a Magnetic drive principle, utilizing a Magnet as the actuating element, providing precise operation. With an assured switching distance (Sao) of 5 mm, 8 mm and an assured switching distance (Sar) of 15 mm, 18 mm it guarantees accurate detection. The sensor comes with a durable 5 m for easy installation, and it supports a maximum switching current of 0.01 A with a switching frequency of up to 5 Hz making it ideal for fast-paced operations. It is rated IP67. Unlock Exclusive Pricing with a Quote for your requirement of Schmersal Magnetic Drive Safety Switch. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
