BNS 16-12ZD-ST3: 101212806 - Schmersal 90 mm Height Magnetic Safety Sensors
Technical Specifications of Schmersal 90 mm Height Magnetic Safety Sensors BNS 16-12ZD-ST3 101212806:
| Working principle | Magnetic drive |
| Connector position | Left |
| Termination | Connector M12 |
| Degree of protection | IP67 |
Schmersal 90 mm Height Magnetic Safety Sensors, BNS 16-12ZD-ST3, 101212806 Technical Specifications:
| Specification | Value |
|---|---|
| Working principle | Magnetic drive |
| Installation conditions (mechanical) | not flush |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Number of normally closed (NC) | 2 |
| Number of normally open (NO) | 1 |
| Active area | cover-side |
| Actuating element | Magnet |
| Direction of motion | Head-on to the active surface |
| Assured switching distance "ON" Sao | 8 mm |
| Assured switching distance "OFF" Sar | 18 mm |
| Connector position | Left |
| Termination | Connector M12 |
| Length of sensor | 39 mm |
| Width of sensor | 52 mm |
| Height of sensor | 90 mm |
| Degree of protection | IP67 |
| Ambient temperature | -25 ... +70 ยฐC |
| Storage and transport temperature | -25 ... +70 ยฐC |
| Resistance to vibrations | 10 โฆ 55 Hz, amplitude 1 mm |
| Restistance to shock | 30 g / 11 ms |
| Switching voltage, maximum | 100 VDC |
| Switching current, maximum | 0.4 A |
| Switching capacity, maximum | 10 W |
| Switching element | 1 NO contact, 2 NC contacts |
| Switching frequency, maximum | 5 Hz |
| Design of control elements | Miscellaneous, Reed contacts |
| Gross weight | 85 g |
Obtain a Quote for Schmersal 90 mm Height Magnetic Safety Sensors BNS 16-12ZD-ST3 part no: 101212806 at economical prices. Specifications Overview for BNS 16-12ZD-ST3, 101212806 reveals Magnetic drive Working principle, featuring a durable Glass-fibre, reinforced thermoplastic housing. The sensor operates with a Magnet actuating element, ensuring reliable performance. It provides an assured switching distance (Sao) of 8 mm and an (Sar) distance of 18 mm making it ideal for precise applications. Termination is facilitated through an Connector M12 ensuring secure and efficient connections. The sensor supports a maximum switching voltage of 100 VDC and a maximum switching current of 0.4 A. It includes both 1 NO contact, 2 NC contacts for versatile operation, with a switching frequency of up to 5 Hz. Rated with an IP67 degree of protection. Take the First Step with a Quote for your requirement of Schmersal 90 mm Height Magnetic Safety Sensors. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
