Schmersal AZR31S1/24VDC Safe Signal Processing
The Schmersal AZR31S1/24VDC Safe Signal Processing (Item No: 101049677) offers a 10,000,000 Operations mechanical life, minimum, 0.25 mm² cable section, minimum, IP40 degree of protection of the enclosure, 24 VDC rated operating voltage. Manufactured by Schmersal under the Schmersal Safe Signal Processing. category, this model belongs to the Schmersal AES Series.
| Brand | Schmersal |
| Product Type | Safe Signal Processing |
| Model Number | AZR31S1/24VDC |
Schmersal AZR31S1/24VDC Safe Signal Processing – Technical Specifications
| Specification | Value |
|---|---|
| Housing material | Glass-fibre, reinforced thermoplastic |
| Number of LEDs | 5 |
| Number of safety contacts | 3 |
| Mechanical life, minimum | 10,000,000 Operations |
| Mounting | Snaps onto standard DIN rail to EN 60715 |
| Terminal designations | IEC/EN 60947-1 |
| Termination | rigid or flexibleScrew terminals M20 x 1.5 |
| Cable section, minimum | 0.25 mm² |
| Cable section, maximum | 2.5 mm² |
| Tightening torque of Clips | 0.6 Nm |
| Width | 45 mm |
| Height | 73.2 mm |
| Depth | 121 mm |
| Degree of protection of the enclosure | IP40 |
| Degree of protection of the mounting space | IP54 |
| Degree of protection of clips or terminals | IP20 |
| Storage and transport temperature | -40 ... +85 °C |
| Resistance to vibrations | 10 ... 55 Hz, Amplitude 0.35 mm |
| Restistance to shock | 30 g / 11 ms |
| Rated impulse withstand voltage Uimp | 4 kV |
| Overvoltage category | III |
| Degree of pollution | 2 |
| Frequency range | 50 Hz60 Hz |
| Operating voltage | 24 VDC -10 % / +20 % |
| Ripple voltage | 10 % |
| Rated operating voltage | 24 VDC |
| Rated AC voltage for controls at DC minimum | 20.4 VDC |
| Contact resistance, maximum | 0.1 Ω |
| Electrical data - Note (Contact resistance) | in new state |
| Drop-out delay in case of power failure, typically | 80 ms |
| Drop-out delay in case of emergency, typically | 20 ms |
| Pull-in delay at RESET, typically | 20 ms |
| Material of the contacts, electrical | AgSn0. self-cleaning, positive drive |
| Voltage, Utilisation category AC-15 | 230 VAC |
| Current, Utilisation category AC-15 | 6 A |
| Voltage, Utilisation category DC-13 | 24 VDC |
| Current, Utilisation category DC-13 | 6 A |
| Switching capacity, minimum | 10 mA |
| Switching capacity, maximum | 8 A |
| Conduction resistance, maximum | 40 Ω |
| Voltage, Utilisation category DC-12 | 24 VDC |
| Current, Utilisation category DC-12 | 0.1 A |
| Switching capacity, maximum | 2 A |
| EMC rating | EMC-Directive |
Get A Quote for Schmersal Safe Signal Processing AZR31S1/24VDC Item No: 101049677 at the best price. Here are the brief Technical Specifications of AZR31S1/24VDC, 101049677 are housing is made of Glass-fibre, reinforced thermoplastic design, ensuring structural integrity and thermal resistance. Termination is achieved via rigid or flexibleScrew terminals M20 x 1.5, supporting cable sections from 0.25 mm² to 2.5 mm². The tightening torque for clips is rated at 0.6 Nm, ensuring secure electrical connections. Compact in size, the unit measures 45 mm in width, 73.2 mm in height, and 121 mm in depth. Terminal clips are rated IP20, providing basic protection against solid objects. Designed to withstand harsh conditions, the unit operates reliably in storage and transport temperatures between -40 ... +85 °C. It resists vibrations of 10 ... 55 Hz, Amplitude 0.35 mm and shock up to 30 g / 11 ms. The rated impulse withstanding voltage (Uimp) is 4 kV. It's Time to get a Quote for your requirement of Safe Signal Processing AZR31S1/24VDC. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
