Schmersal AZM40B-I2-ST-1P2P-PH-DU Solenoid Interlocks
The Schmersal AZM40B-I2-ST-1P2P-PH-DU Solenoid Interlocks (Item No: 103044784) offers a RFID working principle, Connector M12, 8-pole, A-codedtermination, IP66IP67IP69 degree of protection, 32 VDC rated insulation voltage Ui. Manufactured by Schmersal under the Schmersal Solenoid Interlocks. category, this model belongs to the Schmersal AZM Series.
| Brand | Schmersal |
| Product Type | Solenoid Interlocks |
| Model Number | AZM40B-I2-ST-1P2P-PH-DU |
Schmersal AZM40B-I2-ST-1P2P-PH-DU Solenoid Interlocks β Technical Specifications
| Specification | Value |
|---|---|
| Coding level according to EN ISO 14119 | High |
| Working principle | RFID |
| Housing material | Light alloy die cast and plastic (glass-fibre reinforced thermoplastic) |
| Gross weight | 306 g |
| Holding force FZhin accordance with EN ISO 14119 | 2,000 N |
| Latching force | 40 N |
| Actuating speed, maximum | 0.5 m/s |
| Mounting | mounting holes plain |
| Type of the fixing screws | 2x M5 |
| Termination | Connector M12, 8-pole, A-coded |
| Length of sensor | 119.5 mm |
| Width of sensor | 40 mm |
| Height of sensor | 20 mm |
| Degree of protection | IP66IP67IP69 |
| Rated insulation voltage Ui | 32 VDC |
| Rated impulse withstand voltage Uimp | 0.8 kV |
| Required rated short-circuit current | 100 A |
| Magnet switch-on time | 100 % |
| Test pulse duration, maximum | 5 ms |
| Test pulse interval, minimum | 40 ms |
Talk to Our Engineer for Schmersal Solenoid interlocks AZM40B-I2-ST-1P2P-PH-DU part no: 103044784 with exclusive offers. Core System Specifications of AZM40B-I2-ST-1P2P-PH-DU, 103044784 are RFID safety switch, designed for durability and reliability in industrial environments. The housing is made of Light alloy die cast and plastic (glass-fibre reinforced thermoplastic), ensuring a lightweight yet robust construction with a gross weight of 306 g. It features an Connector M12, 8-pole, A-coded system, facilitating easy installation. With dimensions of 119.5 mm in length, 40 mm in width, and 20 mm in height, it is compact yet highly efficient. The IP66IP67IP69 protection rating guarantees resistance against dust, water jets, and temporary immersion, making it suitable for demanding applications. The switch operates at a rated insulation voltage (Ui) of 32 VDC, ensuring electrical safety. Additionally, it has a rated impulse withstand voltage (Uimp) of 0.8 kV, providing high surge protection. Don't Miss Out on a Quote for your requirement of Solenoid interlocks. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
