Schmersal AZM150SK-02/11RIT-024-B6L Solenoid Interlocks
The Schmersal AZM150SK-02/11RIT-024-B6L Solenoid Interlocks (Item No: 153032221) offers a electromechanical working principle, Screw terminalstermination, IP65IP67 degree of protection, 300 V rated insulation voltage Ui. Manufactured by Schmersal under the Schmersal Solenoid Interlocks. category, this model belongs to the Schmersal AZM Series.
| Brand | Schmersal |
| Product Type | Solenoid Interlocks |
| Model Number | AZM150SK-02/11RIT-024-B6L |
Schmersal AZM150SK-02/11RIT-024-B6L Solenoid Interlocks – Technical Specifications
| Specification | Value |
|---|---|
| Coding level according to EN ISO 14119 | High |
| Working principle | electromechanical |
| Housing material | Thermoplastic, Polyamide PA 6 GF |
| Gross weight | 639 g |
| Holding force FZhin accordance with EN ISO 14119 | 1,500 N |
| Latching force | - |
| Positive break travel | 10 mm |
| Positive break force per NC contact, minimum | 10 N |
| Positive break force, minimum | 40 N |
| Actuating speed, maximum | 0.3 m/s |
| Mounting | Screws |
| Type of the fixing screws | 4x M5 |
| Termination | Screw terminals |
| Cable section, minimum | 0.25 mm² |
| Cable section, maximum | 2.5 mm² |
| Length of sensor | 64 mm |
| Width of sensor | 40 mm |
| Height of sensor | 204 mm |
| Degree of protection | IP65IP67 |
| Rated insulation voltage Ui | 300 V |
| Rated impulse withstand voltage Uimp | 4 kV |
| Thermal test current | 5 A |
| Rated control voltage | 24 VDC |
| Required rated short-circuit current | 1,000 A |
| Electrical power consumption, maximum | 8.5 W |
| Switching principle | slow action, positive break NC contact |
| Maximum switching frequency | 1,000 /h |
| Material of the contacts, electrical | Silver |
| Magnet switch-on time | 100 % |
| Test pulse duration, maximum | 5 ms |
| Test pulse interval, minimum | 50 ms |
| Voltage, Utilisation category AC-15 | 230 VAC |
| Voltage, Utilisation category DC-13 | 24 VDC |
| Switching element | NC contact, NO contact |
| Power to unlock | Yes |
| Cable entry | 3 x M20 x 1,5 |
Mail Us for your needs in Schmersal Solenoid interlocks AZM150SK-02/11RIT-024-B6L part no: 153032221 with budget-friendly prices. The Main Technical Parameters of AZM150SK-02/11RIT-024-B6L, 153032221 include electromechanical safety switch, designed for durability and reliability in industrial environments. The housing is made of Thermoplastic, Polyamide PA 6 GF, ensuring a lightweight yet robust construction with a gross weight of 639 g. It features an Screw terminals system, facilitating easy installation. With dimensions of 64 mm in length, 40 mm in width, and 204 mm in height, it is compact yet highly efficient. The IP65IP67 protection rating guarantees resistance against dust, water jets, and temporary immersion, making it suitable for demanding applications. The switch operates at a rated insulation voltage (Ui) of 300 V, ensuring electrical safety. Additionally, it has a rated impulse withstand voltage (Uimp) of 4 kV, providing high surge protection. Customize Your Experience with a Quote for your requirement of Solenoid interlocks. Experience the difference with our competitive pricing and superior support over other Suppliers.
